Sony DCR-SR210E - Electrical Parts List

5-11
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DCR-SR210E/SR220/SR220D/SR220E/
HDR-SR10/SR10D/SR10E_L2
A-1494-347-A CK-196 BOARD, COMPLETE
**********************
< CONNECTOR >
CN5801 1-819-934-61 CONNECTOR, FPC (ZIF) 39P
* CN5802 1-816-650-51 FFC/FPC CONNECTOR (LIF) 24P
CN5803 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
* CN5804 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
< RESISTOR >
R001 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R002 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R003 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R5805 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
< SWITCH >
S5801 1-771-138-21 SWITCH, KEY BOARD (RESET)
S5802 1-771-138-21 SWITCH, KEY BOARD (EASY)
S5803 1-771-138-21 SWITCH, KEY BOARD (DISC BURN)
S5804 1-771-138-21 SWITCH, KEY BOARD (PLAY)
S5805 1-771-138-21 SWITCH, KEY BOARD (DISP/BATT INFO)
S5806 1-786-148-11 SWITCH, PUSH (1 KEY) (PANEL OPEN/CLOSE)
S5808 1-771-731-11 SWITCH, SLIDE (NIGHTSHOT)
S5809 1-771-138-21 SWITCH, KEY BOARD (BACKLIGHT)
************************************************************
Electrical parts list of the CM-093 is not
shown.
Pages 5-12 is not shown.
CK-196
