5-13
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-SR210E/SR220/SR220D/SR220E/
HDR-SR10/SR10D/SR10E_L2
A-1494-350-A CR-091 BOARD, COMPLETE
**********************
< CONNECTOR >
* CN7401 1-821-664-21 CONNECTOR, MULTIPLE (PLUG) 32P
* CN7402 1-821-202-81 CONNECTOR, FPC (ZIF) 45P
************************************************************
1-871-774-11 FP-659 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-659 flexible board.)
************************************************************
1-874-800-11 FP-801 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-801 flexible board.)
************************************************************
1-874-802-11 FP-803 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-803 flexible board.)
************************************************************
1-874-803-11 FP-804 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-804 flexible board.)
************************************************************
1-874-804-11 FP-805 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-805 flexible board.)
************************************************************
1-874-805-11 FP-806 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-806 flexible board.)
************************************************************
1-874-813-11 FP-814 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-814 flexible board.)
************************************************************
1-874-962-11 FP-853 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-853 flexible board.)
************************************************************
A-1494-348-A FP-854 FLEXIBLE BOARD, COMPLETE
******************************
< SWITCH >
S001 1-786-707-11 SWITCH, DETECTION (SMD)
(PANEL REVERSE DETECT)
************************************************************
A-1494-343-A FP-855 FLEXIBLE BOARD, COMPLETE
(HDR-SR10/SR10D/SR10E)
******************************
< CONNECTOR >
CN7191 1-821-166-21 CONNECTOR, HDMI (HDMI OUT)
************************************************************
1-874-965-11 FP-856 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-856 flexible board.)
************************************************************
1-874-967-11 FP-858 FLEXIBLE BOARD
********************
(There isn’t mounted electrical parts in FP-858 flexible board.)
************************************************************
A-1497-997-A FR-285 BOARD, COMPLETE
(HDR-SR10/SR10D/SR10E)
A-1497-998-A FR-285 BOARD, COMPLETE
(DCR-SR210E/SR220/SR220D/SR220E)
**********************
< CAPACITOR >
C9501 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C9503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C9504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C9505 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C9508 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C9509 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C9510 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C9511 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C9512 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C9513 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C9514 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C9515 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C9516 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C9517 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
< CONNECTOR >
* CN9502 1-816-644-51 FFC/FPC CONNECTOR (LIF) 12P
< DIODE >
D9501 6-500-512-01 DIODE CL-330IRS-X-TU (NIGHTSHOT)
D9502 8-719-077-09 DIODE CL-196HR-CD-T (TALLY)
(HDR-SR10/SR10D/SR10E)
< FERRITE BEAD >
FB9501 1-400-833-21 SMD EMI FERRITE
FB9502 1-400-833-21 SMD EMI FERRITE
FB9503 1-400-833-21 SMD EMI FERRITE
FB9504 1-400-833-21 SMD EMI FERRITE
< IC >
IC9501 6-707-333-01 IC NJM3230SE7
IC9502 6-600-163-01 IC RS-770
< COIL >
L9501 1-400-588-11 INDUCTOR 10uH
< RESISTOR >
R9504 1-218-965-11 RES-CHIP 10K 5% 1/16W
R9505 1-218-989-11 RES-CHIP 1M 5% 1/16W
R9506 1-218-989-11 RES-CHIP 1M 5% 1/16W
R9507 1-218-965-11 RES-CHIP 10K 5% 1/16W
R9508 1-218-990-11 SHORT CHIP 0
FR-285
FP-806
FP-858
FP-805
FP-856
FP-804
FP-855
FP-803
FP-854
FP-801
FP-853FP-814
FP-659CR-091
