5-14
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-SR210E/SR220/SR220D/SR220E/
HDR-SR10/SR10D/SR10E_L2
R9510 1-218-945-11 RES-CHIP 220 5% 1/16W
(HDR-SR10/SR10D/SR10E)
R9512 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R9513 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
* RB9501 1-234-379-21 RES, NETWORK 22K (1005X4)
< SENSOR >
* SE9501 1-479-022-51 SENSOR, ANGULAR VELOCITY (PITCH)
* SE9502 1-479-022-61 SENSOR, ANGULAR VELOCITY (YAW)
************************************************************
A-1494-342-A JK-366 BOARD, COMPLETE
**********************
< CONNECTOR >
* CN7201 1-816-648-51 FFC/FPC CONNECTOR (LIF) 20P
CN7202 1-819-436-11 CONNECTOR (SQUARE TYPE) (USB) 5P (USB)
CN7203 1-815-794-13 CONNECTOR (MULTIPLE) (A/V R)
< FERRITE BEAD >
FB7201 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
FB7202 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
< RESISTOR >
R7201 1-216-864-11 SHORT CHIP 0
R7202 1-216-864-11 SHORT CHIP 0
R7203 1-216-809-11 METAL CHIP 100 5% 1/10W
R7204 1-218-990-11 SHORT CHIP 0
R7205 1-218-990-11 SHORT CHIP 0
R7206 1-218-990-11 SHORT CHIP 0
< VARISTOR >
* VD7201 1-802-279-11 VARISTOR (SMD)
* VD7202 1-802-279-11 VARISTOR (SMD)
* VD7203 1-802-279-11 VARISTOR (SMD)
* VD7204 1-802-279-11 VARISTOR (SMD)
* VD7205 1-802-279-11 VARISTOR (SMD)
************************************************************
Electrical parts list of the LD-230 is not
shown.
Pages 5-15 to 5-16 are not shown.
JK-366FR-285
