5-17
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-TRV22/TRV22E
< TRANSFORMER >
0 T6101 1-435-786-31 TRANSFORMER, INVERTER
************************************************************
A-7013-554-A VA-118 BOARD, COMPLETE
**********************
< CAPACITOR >
C4001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4002 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4003 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4005 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4109 1-119-749-11 TANTAL. CHIP 33uF 20% 4V
C4110 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4111 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C4112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4113 1-164-854-11 CERAMIC CHIP 15PF 5% 50V
C4114 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4115 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4116 1-164-854-11 CERAMIC CHIP 15PF 5% 50V
C4117 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4201 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4203 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4204 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4205 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4206 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4207 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C4208 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4209 1-113-986-11 TANTAL. CHIP 2.2uF 20% 25V
C4210 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4211 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4212 1-164-876-11 CERAMIC CHIP 120PF 5% 50V
C4213 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C4214 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C4215 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C4216 1-109-994-11 CERAMIC CHIP 2.2uF 10% 10V
C4217 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C4301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4302 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4303 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C4304 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C4305 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4306 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4307 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4308 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4309 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4310 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4311 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4312 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4314 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4501 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4502 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4503 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4504 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C4505 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4506 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4507 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4508 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4509 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4510 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C4511 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4512 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C4513 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4514 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4515 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C4516 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4517 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4518 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4520 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4521 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4522 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4523 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C4526 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4527 1-127-861-11 CERAMIC CHIP 2.2uF 10% 16V
C4528 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4529 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4530 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4531 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4532 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4533 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4535 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4536 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4537 1-127-861-11 CERAMIC CHIP 2.2uF 10% 16V
C4538 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C4539 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C4540 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C4541 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4542 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4543 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4544 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4545 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4546 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4547 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4548 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C4549 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4550 1-113-988-11 TANTAL. CHIP 68uF 20% 4V
C4551 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4553 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C4554 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4555 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C4557 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C4558 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4559 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4560 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4562 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4601 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4602 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4603 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4604 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C4605 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C4606 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C4607 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
PD-188 VA-118
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
