5-18
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-TRV22/TRV22E
< CONNECTOR >
CN4001 1-691-374-11 CONNECTOR, FFC/FPC 10P
CN4002 1-766-613-21 CONNECTOR, FFC/FPC 36P
CN4003 1-794-998-31 PIN, CONNECTOR 20P
CN4004 1-774-603-21 CONNECTOR, BOARD TO BOARD 100P
CN4005 1-691-354-21 CONNECTOR, FFC/FPC (ZIF) 16P
CN4201 1-766-350-21 CONNECTOR, FFC/FPC 20P
* CN4602 1-580-056-21 PIN, CONNECTOR (SMD) 3P
* CN4603 1-580-056-21 PIN, CONNECTOR (SMD) 3P
< DIODE >
D4001 6-500-289-01 DIODE MAZW082H0LS0
D4002 6-500-289-01 DIODE MAZW082H0LS0
D4101 8-719-073-01 DIODE MA111-(K8).S0
D4102 8-719-056-85 DIODE UDZSTE-178.2B
D4103 8-719-056-85 DIODE UDZSTE-178.2B
D4201 8-719-084-47 DIODE 1SV290(TPL3)
D4502 8-719-421-27 DIODE MA728-(K8).S0
D4503 6-500-314-01 DIODE DAN222MT2L
D4504 8-719-074-08 DIODE MA4ZD03001S0
D4507 8-719-074-08 DIODE MA4ZD03001S0
D4601 6-500-289-01 DIODE MAZW082H0LS0
D4602 8-719-081-19 DIODE 1SS383(T5RSONY1)
D4603 8-719-056-23 DIODE 1SS387-TPL3
D4604 8-719-056-23 DIODE 1SS387-TPL3
< FUSE >
0 F4601 1-576-406-21 FUSE 1.4A 32V
0 F4602 1-576-406-21 FUSE 1.4A 32V
0 F4603 1-576-406-21 FUSE 1.4A 32V
0 F4604 1-576-406-21 FUSE 1.4A 32V
0 F4605 1-576-406-21 FUSE 1.4A 32V
< FERRITE BEAD >
FB4201 1-469-676-22 FERRITE 0uH
FB4202 1-500-329-21 FERRITE 0uH
< IC >
IC4101 6-803-026-01 IC MB89097PFV-G-155-BND-ER-E1
IC4201 8-752-109-08 IC CXA3289BR-T4
IC4202 8-752-405-57 IC CXD3501AR-T4
IC4301 8-759-489-19 IC uPC6756GR-8JG-E2
IC4502 6-703-429-01 IC MB44A120APFV-G-BND-ERE1
IC4504 6-703-227-01 IC TK11131CSCL-G
< COIL >
L4201 1-469-525-91 INDUCTOR 10uH
L4202 1-469-891-21 INDUCTOR 6.8uH
L4301 1-469-570-21 INDUCTOR 10uH
L4501 1-416-670-11 INDUCTOR 33uH
L4502 1-416-669-11 INDUCTOR 22uH
L4503 1-416-669-11 INDUCTOR 22uH
L4504 1-416-669-11 INDUCTOR 22uH
L4505 1-416-670-11 INDUCTOR 33uH
L4506 1-416-669-11 INDUCTOR 22uH
L4507 1-416-670-11 INDUCTOR 33uH
L4508 1-469-524-91 INDUCTOR 4.7uH
L4509 1-469-524-91 INDUCTOR 4.7uH
L4510 1-469-757-21 INDUCTOR 10uH
L4511 1-469-524-91 INDUCTOR 4.7uH
L4512 1-469-524-91 INDUCTOR 4.7uH
L4513 1-469-524-91 INDUCTOR 4.7uH
L4514 1-469-524-91 INDUCTOR 4.7uH
L4515 1-469-526-91 INDUCTOR 22uH
L4516 1-469-524-91 INDUCTOR 4.7uH
L4517 1-469-524-91 INDUCTOR 4.7uH
L4518 1-469-524-91 INDUCTOR 4.7uH
L4519 1-469-524-91 INDUCTOR 4.7uH
L4520 1-469-524-91 INDUCTOR 4.7uH
L4521 1-469-524-91 INDUCTOR 4.7uH
L4601 1-412-056-11 INDUCTOR 4.7uH
< LINE FILTER >
LF4602 1-456-391-21 INDUCTOR 0uH
< TRANSISTOR >
Q4001 6-550-102-01 TRANSISTOR 2SC5663T2L
Q4002 6-550-235-01 TRANSISTOR UNR32A500LS0
Q4003 6-550-238-01 TRANSISTOR UNR31A100LS0
Q4004 8-729-053-57 TRANSISTOR RN1902FE(TPLR3)
Q4005 8-729-054-44 TRANSISTOR RN2902FE(TPLR3)
Q4101 8-729-041-43 TRANSISTOR HN1L02FU(TE85R)
Q4504 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q4505 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q4506 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q4507 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q4508 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q4509 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q4510 6-550-560-01 TRANSISTOR CPH5819-TL-E
Q4513 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q4514 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q4515 6-550-237-01 TRANSISTOR 2SC584600LS0
Q4516 6-550-232-01 TRANSISTOR 2SA207800LS0
Q4517 6-550-232-01 TRANSISTOR 2SA207800LS0
Q4518 8-759-054-50 TRANSISTOR UP04501008S0
Q4519 8-759-054-50 TRANSISTOR UP04501008S0
Q4520 6-550-237-01 TRANSISTOR 2SC584600LS0
Q4521 8-729-054-49 TRANSISTOR UP04401008S0
Q4524 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q4525 8-759-054-50 TRANSISTOR UP04501008S0
Q4526 6-550-406-01 TRANSISTOR MCH3335-S-TL-E
Q4601 8-729-047-68 TRANSISTOR SSM3K03FE(TPL3)
Q4602 6-550-404-01 TRANSISTOR UPA1858GR-9JG-E2-A
Q4603 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q4604 6-550-234-01 TRANSISTOR UNR32A300LS0
Q4608 8-729-056-19 TRANSISTOR TPC6101(TE85R)
Q4610 6-550-234-01 TRANSISTOR UNR32A300LS0
VA-118
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
To Next Page
