5-19
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-TRV22/TRV22E
< RESISTOR >
R4002 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4004 1-216-009-91 RES-CHIP 22 5% 1/10W
R4005 1-216-009-91 RES-CHIP 22 5% 1/10W
R4006 1-218-939-11 RES-CHIP 68 5% 1/16W
R4007 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R4008 1-218-990-11 SHORT CHIP 0
R4009 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4103 1-218-989-11 RES-CHIP 1M 5% 1/16W
R4104 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4105 1-218-990-11 SHORT CHIP 0
R4106 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4109 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4110 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4111 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4112 1-218-989-11 METAL CHIP 1M 0.5% 1/16W
R4113 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4114 1-219-570-11 METAL CHIP 10M 5% 1/10W
R4115 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R4116 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4117 1-218-990-11 SHORT CHIP 0
R4118 1-216-857-11 METAL CHIP 1M 5% 1/16W
R4119 1-218-949-11 RES-CHIP 470 5% 1/16W
R4120 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4121 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4122 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4123 1-218-989-11 RES-CHIP 1M 5% 1/16W
R4124 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4201 1-218-985-11 RES-CHIP 470K 5% 1/16W
R4202 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4204 1-218-990-11 SHORT CHIP 0
R4206 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R4207 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4208 1-218-975-11 RES-CHIP 68K 5% 1/16W
R4209 1-218-969-11 RES-CHIP 22K 5% 1/16W
R4210 1-218-975-11 RES-CHIP 68K 5% 1/16W
R4211 1-218-989-11 RES-CHIP 1M 5% 1/16W
R4212 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4213 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4214 1-218-989-11 METAL CHIP 1M 0.5% 1/16W
R4215 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4301 1-218-989-11 RES-CHIP 1M 5% 1/16W
R4302 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4303 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4304 1-218-989-11 RES-CHIP 1M 5% 1/16W
R4501 1-220-200-81 RES-CHIP 30K 5% 1/16W
R4502 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4503 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4504 1-218-990-11 SHORT CHIP 0
R4505 1-218-990-11 SHORT CHIP 0
R4506 1-218-990-11 SHORT CHIP 0
R4507 1-218-990-11 SHORT CHIP 0
R4508 1-218-990-11 SHORT CHIP 0
R4509 1-218-990-11 SHORT CHIP 0
R4510 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4511 1-218-970-11 RES-CHIP 27K 5% 1/16W
R4512 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4513 1-218-971-11 RES-CHIP 33K 5% 1/16W
R4514 1-218-972-11 RES-CHIP 39K 5% 1/16W
R4515 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4516 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4517 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R4518 1-208-910-11 RES-CHIP 9.1K 5% 1/16W
R4519 1-218-990-11 SHORT CHIP 0
R4520 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4522 1-218-990-11 SHORT CHIP 0
R4523 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4524 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R4525 1-218-990-11 SHORT CHIP 0
R4526 1-218-935-11 RES-CHIP 33 5% 1/16W
R4537 1-218-966-11 RES-CHIP 12K 5% 1/16W
R4538 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4539 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4540 1-218-973-11 RES-CHIP 47K 5% 1/16W
R4541 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4543 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4545 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4546 1-218-969-11 RES-CHIP 22K 5% 1/16W
R4547 1-218-969-11 RES-CHIP 22K 5% 1/16W
R4549 1-218-969-11 RES-CHIP 22K 5% 1/16W
R4550 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R4551 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4552 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4553 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4554 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R4555 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4556 1-218-967-11 RES-CHIP 15K 5% 1/16W
R4557 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R4561 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4562 1-218-949-11 RES-CHIP 470 5% 1/16W
R4563 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R4564 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R4567 1-218-990-11 SHORT CHIP 0
R4601 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4604 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4605 1-218-989-11 RES-CHIP 1M 5% 1/16W
R4607 1-216-797-11 METAL CHIP 10 5% 1/16W
R4608 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R4609 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R4611 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4614 1-218-989-11 RES-CHIP 1M 5% 1/16W
R4615 1-218-965-11 RES-CHIP 10K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB4101 1-234-378-21 RES, NETWORK 10KX4 (1005)
RB4104 1-234-375-21 RES, NETWORK 1KX4 (1005)
RB4105 1-234-375-21 RES, NETWORK 1KX4 (1005)
RB4106 1-234-375-21 RES, NETWORK 1KX4 (1005)
RB4107 1-234-375-21 RES, NETWORK 1KX4 (1005)
RB4108 1-234-375-21 RES, NETWORK 1KX4 (1005)
RB4109 1-234-381-21 RES, NETWORK 100KX4 (1005)
VA-118
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
