2-1
SECTION 2
DISASSEMBLY
DCR-TRV820/TRV820E/TRV820P
• This set can be disassembled in the order shown below.
DCR-TRV820/TRV820E/TRV820P
2-3. FRONT PANEL ASSEMBLY
(page 2-4)
2-5. CABINET (R) ASSEMBLY
(page 2-5)
2-4. CASSETTE LID ASSEMBLY,
CABINET (L) ASSEMBLY
(page 2-4)
Note:Use the parts only which
can be removed easily
from outside of the
MECHANISM DECK.
2-7. CABINET (L) ASSEMBLY
(page 2-6)
2-11. LENS BLOCK
(page 2-8)
2-9. PR-33 BOARD,
PRINTER UNIT
(page 2-6)
2-1. LCD ASSEMBLY, PD-118 BOARD
(page 2-2)
2-2. VF-141 BOARD, VF LENS ASSEMBLY
(page 2-3)
MECHANISM DECK
SERVICE POSITION
(page 2-4)
MECHANISM DECK,
VC-235 BOARD
SERVICE POSITION
(page 2-9)
PC-78 BOARD
SERVICE POSITION
(page 2-5)
PR-33 BOARD
SERVICE POSITION
(page 2-7)
2-13. FU-141 BOARD
(page 2-8)
2-6. PC-78 BOARD
(page 2-5)
2-8. BATTERY PANEL
ASSEMBLY
(page 2-6)
2-12. SE-114 BOARD,
CONTROL SWITCH
BLOCK (FK-10000)
(page 2-8)
LCD SERVICE POSITION
(page 2-2)
EVF SERVICE POSITION
(page 2-3)
2-14. VC-235 BOARD
(page 2-8)
