Location and Function of Parts
1 Headphones jack
2 Strap hole
3 Clip hole
4 Indicator (red)
Indicates the power status of the
unit.
5 Microphone
6 Multi function button
Controls various call functions.
7 Indicator (blue)
Indicates the communication
status of the unit.
8 Jog switch
Controls various functions
when listening to music.
Adjust the volume of the unit
when talking over the
telephone.
9 RESET button
0 Contact point
qa POWER button
GETTING STARTED
