5-10
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-P10/P12
C503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C506 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C507 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C508 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C509 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C510 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C511 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C512 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C513 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C515 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C516 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C517 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C518 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C521 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C525 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C526 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C601 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C602 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C603 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C604 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C606 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C607 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C608 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C609 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C610 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C611 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C612 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C613 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C614 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C615 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C616 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C617 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C618 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C619 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C620 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C621 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C622 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C623 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C624 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C625 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C626 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C627 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C632 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C634 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C801 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C802 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C803 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
< CONNECTOR >
CN151 1-794-409-21 CONNECTOR, FPC (ZIF) 39P
CN301 1-794-408-21 CONNECTOR, FPC (ZIF) 27P
CN351 1-815-330-11 CONNECTOR, FPC (ZIF) 15P
CN801 1-794-411-21 CONNECTOR, FFC/FPC (LIF) 8P
CN802 1-816-057-11 CONNECTOR, FPC (ZIF) 39P
SY-83
CN803 1-794-375-21 PIN, CONNECTOR 2P
CN804 1-815-343-11 CONNECTOR, FFC/FPC 14P
CN805 1-816-057-11 CONNECTOR, FPC (ZIF) 39P
< DIODE >
D001 8-719-056-23 DIODE MA2S111- (K8).SO
D002 8-719-158-49 DIODE RD12SB2
D003 8-719-027-76 DIODE 1SS357-TPH3
D004 8-719-069-29 DIODE RB520S-30TE61
D006 6-500-186-01 DIODE MA2SD24008S0
D007 6-500-186-01 DIODE MA2SD24008S0
D008 6-500-186-01 DIODE MA2SD24008S0
D009 6-500-186-01 DIODE MA2SD24008S0
D010 8-719-085-69 DIODE 015AZ6.2-Z (TPL3)
D011 6-500-186-01 DIODE MA2SD24008S0
D012 8-719-085-69 DIODE 015AZ6.2-Z (TPL3)
D014 8-719-069-29 DIODE RB520S-30TE61
D151 8-719-056-23 DIODE MA2S111- (K8).SO
D402 8-719-027-76 DIODE 1SS357-TPH3
D403 8-719-056-23 DIODE MA2S111- (K8).SO
D404 8-719-073-03 DIODE MA8082- (K8).S0
D801 6-500-186-01 DIODE MA2SD24008S0
D802 8-719-066-44 DIODE CL-270HR-C-TS (MS ACCESS)
D803 8-719-056-23 DIODE MA2S111- (K8).SO
D804 8-719-073-03 DIODE MA8082- (K8).S0
< FUSE >
0 F001 1-576-716-21 FUSE (2A/24V)
0 F002 1-576-716-21 FUSE (2A/24V)
0 F003 1-576-716-21 FUSE (2A/24V)
0 F004 1-576-716-21 FUSE (2A/24V)
< FERRITE BEAD >
* FB151 1-469-876-11 FERRITE 0uH
FB152 1-414-228-11 FERRITE 0uH
FB153 1-414-228-11 FERRITE 0uH
FB154 1-414-228-11 FERRITE 0uH
FB155 1-469-082-21 FERRITE 0uH
FB156 1-469-082-21 FERRITE 0uH
FB504 1-500-284-21 FERRITE 0uH
FB505 1-500-283-11 FERRITE 0uH
FB506 1-500-283-11 FERRITE 0uH
FB507 1-500-283-11 FERRITE 0uH
< IC >
IC001 6-703-410-01 IC FA7712Q-D-TE2
0 IC002 6-550-352-01 TRANSISTOR FDW2508P/N (Note 1)
IC003 6-700-429-01 IC S-8321ADMP-DND-T2
IC101 6-700-428-01 IC NJM2574RB1 (TE2)
IC151 8-752-422-65 IC CXD3440GA-T4
IC152 A-7078-663-A CH-122 BOARD, COMPLETE
IC201 6-703-734-01 IC AN12908A-VB
IC301 6-701-957-01 IC M50230FP-DF0T
0 IC351 6-703-635-01 IC TND721MH5-S-TL-E
IC402 6-803-134-01 IC MB89097LGA-G-157-ER
IC403 6-703-060-01 IC S-8425AABPA-TF-G
IC501 (Note 2) IC HJ93D1702CLPZ
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Note 1: Transistor is mounted to the location where
IC002 is printed.
Note 2: Part number is not fixed yet.
It will be notified by Supplement of Service
Manual when it is fixed.
To Next Page
