5-11
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-P10/P12
IC502 6-703-406-01 IC CY27030ZCT
IC503 6-701-985-01 IC BH2220FVM-TR
IC504 6-700-770-01 IC BR9016ARFVM-WTR
IC601 A-7078-638-A HM (5M MI) BOARD, COMPLETE
IC602 8-752-422-68 IC CXD3176GA-T2
< COIL >
L001 1-456-135-11 INDUCTOR 4.7uH
L002 1-456-137-11 INDUCTOR 22uH
L003 1-419-627-21 INDUCTOR 10uH
L004 1-419-311-21 INDUCTOR 100uH
L005 1-419-627-21 INDUCTOR 10uH
L006 1-456-137-11 INDUCTOR 22uH
L007 1-456-137-11 INDUCTOR 22uH
L008 1-456-137-11 INDUCTOR 22uH
L009 1-419-311-21 INDUCTOR 100uH
L010 1-469-757-21 INDUCTOR 10uH
L151 1-469-561-21 INDUCTOR 100uH
L152 1-469-527-91 INDUCTOR 47uH
L153 1-469-525-91 INDUCTOR 10uH
L154 1-469-525-91 INDUCTOR 10uH
L201 1-469-555-21 INDUCTOR 10uH
L202 1-469-555-21 INDUCTOR 10uH
L302 1-414-771-91 INDUCTOR 10uH
L303 1-414-771-91 INDUCTOR 10uH
L351 1-412-027-11 INDUCTOR 2.2uH
L401 1-469-559-21 INDUCTOR 47uH
L502 1-469-757-21 INDUCTOR 10uH
L601 1-469-757-21 INDUCTOR 10uH
< TRANSISTOR >
0 Q001 8-729-047-68 TRANSISTOR SSM3K03FE (TPL3)
Q002 6-550-119-01 TRANSISTOR DTC144EMT2L
Q003 8-729-055-87 TRANSISTOR MCH5801-TL-E
0 Q005 8-729-043-94 TRANSISTOR CPH3106-TL-E
0 Q006 6-550-119-01 TRANSISTOR DTC144EMT2L
Q007 8-729-055-88 TRANSISTOR MCH3406-TL-E
Q008 6-550-408-01 TRANSISTOR QS5U26TR
Q009 6-550-171-01 TRANSISTOR MCH3317-TL-E
Q010 6-550-171-01 TRANSISTOR MCH3317-TL-E
Q011 6-550-171-01 TRANSISTOR MCH3317-TL-E
Q012 8-729-055-88 TRANSISTOR MCH3406-TL-E
Q013 8-729-055-88 TRANSISTOR MCH3406-TL-E
Q014 8-729-055-87 TRANSISTOR MCH5801-TL-E
Q015 8-729-055-87 TRANSISTOR MCH5801-TL-E
Q016 8-729-055-88 TRANSISTOR MCH3406-TL-E
Q017 8-729-053-76 TRANSISTOR CPH5802-TL-E
Q018 8-729-053-76 TRANSISTOR CPH5802-TL-E
Q019 6-550-189-01 TRANSISTOR ECH8603-TL-E
Q151 8-729-427-72 TRANSISTOR XP4501
Q152 6-550-271-01 TRANSISTOR DTA114YMT2L
Q153 6-550-268-01 TRANSISTOR DTC114YMT2L
Q154 6-550-271-01 TRANSISTOR DTA114YMT2L
Q155 6-550-268-01 TRANSISTOR DTC114YMT2L
Q302 8-729-049-11 TRANSISTOR CPH3206-TL-E
Q303 8-729-053-29 TRANSISTOR DTA143TMT2L
0 Q351 8-729-054-48 TRANSISTOR UP04601008S0
0 Q352 6-550-119-01 TRANSISTOR DTC144EMT2L
0 Q353 6-550-528-01 TRANSISTOR UPA650TT-E1-A
0 Q354 8-729-053-57 TRANSISTOR RN1902FE (TPLR3)
Q402 6-550-119-01 TRANSISTOR DTC144EMT2L
Q407 6-550-119-01 TRANSISTOR DTC144EMT2L
Q408 8-729-041-43 TRANSISTOR HN1L02FU (TE85R)
Q409 6-550-119-01 TRANSISTOR DTC144EMT2L
Q410 6-550-119-01 TRANSISTOR DTC144EMT2L
Q411 6-550-175-01 TRANSISTOR DTC143TMT2L
Q501 6-550-119-01 TRANSISTOR DTC144EMT2L
Q502 6-550-239-01 TRANSISTOR DTA144EMT2L
Q602 6-550-119-01 TRANSISTOR DTC144EMT2L
Q603 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q604 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q605 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q606 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q607 6-550-271-01 TRANSISTOR DTA114YMT2L
Q802 6-550-576-01 TRANSISTOR SSM6E01TU (TE85R)
< RESISTOR >
R001 1-211-969-11 METAL CHIP 10 0.5% 1/10W
R002 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R003 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R004 1-208-709-11 METAL CHIP 12K 0.5% 1/16W
R005 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R006 1-218-960-11 RES-CHIP 3.9K 5% 1/16W
R007 1-218-977-11 RES-CHIP 100K 5% 1/16W
R008 1-218-969-11 RES-CHIP 22K 5% 1/16W
R009 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R010 1-218-968-11 RES-CHIP 18K 5% 1/16W
R011 1-218-978-11 RES-CHIP 120K 5% 1/16W
R012 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R013 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R014 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R015 1-218-985-11 RES-CHIP 470K 5% 1/16W
R016 1-218-990-11 SHORT CHIP 0
R017 1-218-989-11 RES-CHIP 1M 5% 1/16W
R018 1-218-987-11 RES-CHIP 680K 5% 1/16W
R019 1-218-973-11 RES-CHIP 47K 5% 1/16W
R020 1-218-892-11 METAL CHIP 75K 0.5% 1/16W
R021 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R022 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R023 1-218-990-11 SHORT CHIP 0
R024 1-218-990-11 SHORT CHIP 0
R025 1-218-970-11 METAL CHIP 27K 0.5% 1/16W
R026 1-218-990-11 SHORT CHIP 0
R027 1-218-990-11 SHORT CHIP 0
R028 1-218-990-11 SHORT CHIP 0
R029 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R032 1-218-949-11 RES-CHIP 470 5% 1/16W
R033 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R034 1-218-949-11 RES-CHIP 470 5% 1/16W
R035 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R036 1-218-949-11 RES-CHIP 470 5% 1/16W
R037 1-208-944-81 METAL CHIP 240K 0.5% 1/16W
R038 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R039 1-208-635-11 RES-CHIP 10 5% 1/16W
R040 1-218-953-11 RES-CHIP 1K 5% 1/16W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
SY-83
