DSC-P32
5-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
SECTION 5
REPAIR PARTS LIST
COVER
COVER
5-7
Ref. No. Part No. Description Ref. No. Part No. Description
A-7078-685-A SY-84 BOARD, COMPLETE (SERVICE)
******************************
(IC351 is not included in this COMPLETE)
(Incuding IC301 (HM (3M SA) BOARD))
(Incuding IC901 (CH-122 (3M) BOARD))
< CAPACITOR >
C001 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C002 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C003 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C004 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C005 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C006 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C007 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C008 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C009 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C010 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C012 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C013 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C014 1-164-874-11 CERAMIC CHIP 100PF 5.00% 50V
C015 1-164-874-11 CERAMIC CHIP 100PF 5.00% 50V
C016 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C017 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C018 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C019 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C020 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C021 1-107-682-11 CERAMIC CHIP 1uF 10.00% 16V
C022 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C023 1-107-682-11 CERAMIC CHIP 1uF 10.00% 16V
C024 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C025 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C026 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C028 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C029 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C030 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C031 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C032 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C033 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C034 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C035 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C036 1-100-503-11 CERAMIC CHIP 4.7uF 10% 10V
C037 1-165-596-11 CERAMIC CHIP 2.2uF 35V
C038 1-164-336-11 CERAMIC CHIP 0.33uF 25V
C039 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
C040 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C041 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C042 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C043 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C044 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C045 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C046 1-113-682-11 TANTAL. CHIP 33uF 20.00% 10V
C048 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C049 1-164-299-11 CERAMIC CHIP 0.22uF 10.00% 25V
C050 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C052 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C053 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C152 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C153 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C154 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C155 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C156 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C157 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C158 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C159 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C160 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C161 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V
C162 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V
C163 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C164 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C165 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C166 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C167 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C168 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C169 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C170 1-135-259-11 TANTAL. CHIP 10uF 20.00% 6.3V
C171 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C173 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C174 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C175 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C176 1-119-923-81 CERAMIC CHIP 0.047uF 10.00% 10V
C177 1-119-923-81 CERAMIC CHIP 0.047uF 10.00% 10V
C178 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C179 1-104-851-11 TANTAL. CHIP 10uF 20.00% 10V
C180 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C201 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C202 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C203 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C204 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C205 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C206 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V
C207 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V
C208 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V
SY-84
