Sony DSC-P32 - Page 24

5-9
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-P32
C907 1-110-569-11 TANTAL. CHIP 47uF 20.00% 6.3V
C908 1-110-569-11 TANTAL. CHIP 47uF 20.00% 6.3V
C909 1-104-752-11 TANTAL. CHIP 33uF 20.00% 6.3V
C912 1-119-751-11 TANTAL. CHIP 22uF 20.00% 16V
< CONNECTOR >
CN001 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD)4P
CN201 1-816-645-11 FFC/FPC CONNECTOR (LIF) 14P
CN202 1-794-375-21 PIN, CONNECTOR 2P
CN701 1-817-544-11 CONNECTOR, FPC (ZIF) 39P
CN702 1-817-544-11 CONNECTOR, FPC (ZIF) 39P
CN704 1-816-644-11 FFC/FPC CONNECTOR (LIF) 12P
CN705 1-794-767-31 FFC/FPC CONNECTOR (LIF) 10P
CN706 1-794-767-31 FFC/FPC CONNECTOR (LIF) 10P
< DIODE >
D001 8-719-073-01 DIODE MA111-(K8).S0
D002 8-719-073-01 DIODE MA111-(K8).S0
D003 8-719-073-01 DIODE MA111-(K8).S0
D004 8-719-056-23 DIODE MA2S111-(K8).SO
D005 8-719-158-49 DIODE MA8120-TX
D009 6-500-186-01 DIODE MA2SD24008S0
D010 6-500-186-01 DIODE MA2SD24008S0
D011 6-500-186-01 DIODE MA2SD24008S0
D012 6-500-186-01 DIODE MA2SD24008S0
D013 6-500-186-01 DIODE MA2SD24008S0
D014 6-500-186-01 DIODE MA2SD24008S0
D015 8-719-081-34 DIODE RB160M-30TR
D016 6-500-186-01 DIODE MA2SD24008S0
D017 8-719-085-69 DIODE 015AZ6.2-Z(TPL3)
D018 8-719-056-23 DIODE MA2S111-(K8).SO
D019 8-719-085-69 DIODE 015AZ6.2-Z(TPL3)
D020 8-719-069-29 DIODE RB520S-30TE61
D201 8-719-073-01 DIODE MA111-(K8).S0
D202 8-719-075-62 DIODE 1SS401(TE85L)
D351 8-719-056-23 DIODE MA2S111-(K8).SO
D401 8-719-027-76 DIODE 1SS357-TPH3
D701 6-500-186-01 DIODE MA2SD24008S0
D702 8-719-064-07 DIODE SML-310LTT86
D703 8-719-053-07 DIODE SML-310MTT86
D704 8-719-060-92 DIODE SML-311YTT86
D705 8-719-064-07 DIODE SML-310LTT86
D706 8-719-075-15 DIODE MAZT082H08S0
D707 8-719-075-15 DIODE MAZT082H08S0
D708 8-719-075-15 DIODE MAZT082H08S0
D709 8-719-075-15 DIODE MAZT082H08S0
D710 8-719-056-61 DIODE MAZS082008SO
D711 8-719-056-61 DIODE MAZS082008SO
D712 8-719-056-23 DIODE MA2S111-(K8).SO
D713 8-719-056-23 DIODE MA2S111-(K8).SO
D803 8-719-084-47 DIODE 1SV290(TPL3)
< FUSE >
0 F001 1-576-716-11 MICRO FUSE-LINKS (1005) 2A/24V
0 F003 1-576-716-11 MICRO FUSE-LINKS (1005) 2A/24V
0 F005 1-576-716-11 MICRO FUSE-LINKS (1005) 2A/24V
0 F007 1-576-716-11 MICRO FUSE-LINKS (1005) 2A/24V
< FERRITE BEAD >
FB019 1-469-581-21 FERRITE 0uH
FB301 1-414-921-11 FERRITE 0uH
FB302 1-414-921-11 FERRITE 0uH
FB303 1-414-921-11 FERRITE 0uH
FB351 1-414-228-11 FERRITE 0uH
FB501 1-414-921-11 FERRITE 0uH
FB502 1-414-921-11 FERRITE 0uH
FB503 1-414-921-11 FERRITE 0uH
FB504 1-500-284-21 FERRITE 0uH
FB701 1-469-185-11 FERRITE 0uH
FB702 1-469-185-11 FERRITE 0uH
FB703 1-414-228-11 FERRITE 0uH
FB704 1-500-284-21 FERRITE 0uH
FB705 1-500-284-21 FERRITE 0uH
FB781 1-414-921-11 FERRITE 0uH
FB801 1-500-283-11 FERRITE 0uH
FB901 1-234-576-21 FILTER, CHIP EMI
FB902 1-414-228-11 FERRITE 0uH
FB903 1-414-228-11 FERRITE 0uH
FB904 1-414-228-11 FERRITE 0uH
FB905 1-469-082-21 FERRITE 0uH
FB906 1-469-082-21 FERRITE 0uH
< IC >
IC001 6-703-410-01 IC FA7712Q-D-TE2
IC003 6-702-371-01 IC XC61CC1502NR
IC004 6-700-429-01 IC S-8321ADMP-DND-T2
IC101 Note IC CXD3430GA-T4
IC151 6-703-734-01 IC AN12908A-VB
IC201 8-759-337-40 IC NJM2904V(TE2)
IC202 8-759-681-42 IC NJM12902V(TE2)
IC203 8-759-637-96 IC uPD16877MA-6A5-E2
IC204 6-702-155-01 IC BH2223FV-E2
IC205 6-701-956-01 IC LB1938T-TLM-E
IC301 A-7078-644-A HM (3M SA) BOARD, COMPLETE
IC351 A-7013-723-A CCD BLOCK ASSY (CCD IMAGER) (Note)
(IC351 is not included in this COMPLETE)
IC401 6-802-790-01 IC MB89097LGA-G-151-ER
IC402 6-703-060-01 IC S-8425AABPA-TF-G
IC501 Note IC HJ93D1702LPZ
IC502 6-702-923-01 IC AK6417CH-E2
IC601 6-700-428-01 IC NJM2574RB1(TE2)
IC781 6-700-962-01 IC SM8720AV-E2
IC801 6-702-491-01 IC AN12580A-BB
IC802 8-759-833-18 IC CM7021L3-E2
IC901 A-7078-599-A CH-122 (3M) BOARD, COMPLETE
< COIL >
L001 1-456-135-11 CHOKE COIL (4.7uH)
L002 1-456-137-11 CHOKE COIL (22uH)
L003 1-419-627-21 INDUCTOR 10uH
L004 1-456-017-11 INDUCTOR 100uH
L005 1-424-846-11 INDUCTOR 0uH
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SY-84
Note :
Part number is not fixed yet. It will be notified Technical News when
it fixed.
Be sure to read “Precautions upon replacing CCD imager”
on page 4-8 when changing the CCD imager.
