Sony DSC-R1 Service Manual

DSC-R1_L2
2. DISASSEMBLY
2. DISASSEMBLY
2-3 2-4
The following flow chart shows the disassembly procedure.
2-1. DISASSEMBLY
HELP
HELP
1 Open the LCD.
2 P2 screw (M2x4) (black)
x8
3 Remove the cabinet (rear) block.
4 Flexible board
x1
5 Cabinet (rear) block
1 Remove the fuse replacement caution label.
2 Flexible board
x4
3 P2 screw (M2x4) (black) x4
4 Center block assembly
1 Flexible board
x2
2 Cabinet upper assembly
3 Discharging the Capacitor.
1 Claw
x2
2 Remove the cabinet
(side) block assembly.
3 Flexible board
x1
4 Cabinet (side) block assembly
5 Flexible board
x2
6 Claw x2
7 EVF block assembly
1 Connector
x2
2 Fuse replacement caution label
3 P2 tapping screw (M1.7x3) (silver)
x6
4 Boss x1
5 SY board
1 Open the LCD.
2 P2 screw (M2x4) (black)
x2
3 Claw x4
4 LC case (L)
5 Tape (A)
x1
6 Flexible board x2
7 P2 tapping screw (M1.7x3) (silver) x1
8 PD board
9 P2 tapping screw (M1.7x4) (black)
x2
0 P2 tapping screw (M1.7x4) (black) x4
qa LC retainer
qs LC case block
qd LCD901, D901
2
2
2
2
2
3
4
5
1
Refer to page 2-1
" Discharging of the ST-128 board's
charging capacitor (C104) ",
when discharging the capacitor.
3
4
3
3
3
1
2
2
1
1
5
2
3
6
7
4
2
3
1
2
3
5
6
7
8
0
0
qa
9
qs
qd
6
4
3
2
4
5
1
HELP
HELP
