Sony DSC-R1 Service Manual

— 2 —
DSC-R1_L2
SPECIFICATIONS
Camera
[System]
Image device 21.5 × 14.4 mm color CMOS
sensor, Primary 3-color filter
Total pixel number of camera
Approx. 10 784 000 pixels
Effective pixel number of camera
Approx. 10 286 000 pixels
Lens Carl Zeiss Vario-Sonnar T*
5× zoom lens
f = 14.3 − 71.5 mm (24 −
120mm when converted to a
35 mm still camera)
F2.8 − 4.8
Filter diameter: 67 mm
Exposure control Automatic, Shutter speed
priority, Aperture priority,
Manual exposure, Scene
selection (4 modes)
White balance Automatic, Daylight, Cloudy,
Fluorescent, Incandescent,
Flash, One-push
File format (DCF compliant)
Still images: Exif Ver. 2.21
JPEG compliant, RAW (SR2),
DPOF compatible
Recording media “Memory Stick”
Microdrive
CompactFlash card (TypeI/
TypeII)
Flash Recommended distance (ISO
set to Auto): approx. 0.5 m to
8.5 m (1 feet 7 3/4 inches to 27
feet 10 3/4 inches) (W)/approx.
0.4 m to 5.0 m (1 feet 3 3/4
inches to 16 feet 4 7/8 inches)
(T)
Viewfinder Electric viewfinder (color)
[Input and Output connectors]
VIDEO OUT jack
Minijack
1 Vp-p, 75 Ω, unbalanced, sync
negative
ACC jack Mini-minijack (ø 2.5 mm)
USB jack mini-B
USB communication
Hi-Speed USB (USB 2.0
compliant)
[LCD screen]
LCD panel 5.1 cm (2.0 type) TFT drive
Total number of dots
134 000 (560 × 240) dots
[Finder]
LCD panel 1.1 cm (0.44 type) TFT drive
Total number of dots
235 200 (980 × 240) dots
[Power, general]
Used battery pack
Rechargeable battery pack
NP-FM50
Power requirements
7.2 V
Power consumption (during shooting with LCD
on)
1.7 W
Operating temperature
0°C to +40°C (+32°F to
+104°F)
(When using the Microdrive:
+5°C to +40°C (41°F to
+104°F))
Storage temperature
−20°C to +60°C (−4°F to
+140°F)
Dimensions (lens: W-end)
139.4 × 97.7 × 156.0 mm
(5 1/2 × 3 7/8 × 6 1/4 inches)
(W/H/D, excluding protrusions)
Mass Approx. 1047 g (2 lb 4.9 oz)
(including NP-FM50 battery
pack, “Memory Stick”,
shoulder strap, and lens hood,
etc.)
Speaker Dynamic speaker
Exif Print Compatible
PRINT Image Matching III
Compatible
PictBridge Compatible
AC-L15A AC Adaptor
Input rating 100 V to 240 V AC, 50/60 Hz,
18 W
Output rating 8.4 V DC*
*See the label on the AC
Adaptor for other
specifications.
Operating temperature range
0°C to +40°C (32°F to +104°F)
Storage temperature range
-20°C to +60°C (-4°F to
+140°F)
Maximum dimensions
Approx. 56 × 31 × 100 mm
(2 1/4 × 1 1/4 × 4 inches) (W/H/
D), excluding projecting parts
Mass Approx. 190 g (6.7 oz)
excluding power cord (mains
lead)
Rechargeable battery pack NP-FM50
Used battery Lithium-ion battery
Maximum voltage
DC 8.4 V
Nominal voltage DC 7.2 V
Capacity 8.5 Wh (1 180 mAh)
Design and specifications are subject to change
without notice.

Sony DSC-R1 Specifications

General

Sensor Type	CMOS
Sensor Size	21.5 x 14.4 mm
Effective Pixels	10.3 Megapixels
Lens	Carl Zeiss Vario-Sonnar T*
Focal Length	24-120 mm (35mm equivalent)
ISO Sensitivity	160-3200
Shutter Speed	30 - 1/2000 sec
Image Formats	JPEG, RAW
Battery	NP-FM50 InfoLithium rechargeable battery
Weight	995 g (including battery)
Aperture Range	f/2.8-4.8
LCD Screen	2.0-inch, 134, 000 pixels
Viewfinder	Electronic (EVF), 235, 000 pixels
Storage Media	CompactFlash, Memory Stick
Dimensions	139 x 97 x 156 mm
Camera Type	Digital SLR-like camera
