Sony DSC-R1 Service Manual

1-2
DSC-R1_L2
1-2. PRECAUTION ON REPLACING THE SY-132 BOARD
VIDEO OUT Default Data Check
When you replace to the repairing board, the written data of repairing board also might be changed to original setteing because of broadcast
system (NTSC/PAL).
When the data has changed because of board replaceing etc, check the default data of VIDEO OUT if destination code is right. If not, rewrite
to the right value.
VIDEO OUT Default Data
Writing Method:
1) Select page: 00, address: 01 and set data: 01.
2) Select page: 4F, address: 8D, and set data: 00 (NTSC) or data: 01 (PAL).
3) Select page: 4F, address: A2, and set data: 00 (NTSC) or data: 01 (PAL).
4) Select page: 40, address: 38, and set data: 00.
5) Click [Save] on the SEUS screen.
6) Select page: 80, address: 34, and check that the data is “00”.
7) Select page: 80, address: 30, and check that the data is “00”.
8) Select page: 00, address: 01, and set data: 00.
Address
00
00
01
01
8D
A2
4F
4F
Page
Data
NTSC PAL
Ver 1.1 2005.11

Sony DSC-R1 Specifications

General

Sensor Type	CMOS
Sensor Size	21.5 x 14.4 mm
Effective Pixels	10.3 Megapixels
Lens	Carl Zeiss Vario-Sonnar T*
Focal Length	24-120 mm (35mm equivalent)
ISO Sensitivity	160-3200
Shutter Speed	30 - 1/2000 sec
Image Formats	JPEG, RAW
Battery	NP-FM50 InfoLithium rechargeable battery
Weight	995 g (including battery)
Aperture Range	f/2.8-4.8
LCD Screen	2.0-inch, 134, 000 pixels
Viewfinder	Electronic (EVF), 235, 000 pixels
Storage Media	CompactFlash, Memory Stick
Dimensions	139 x 97 x 156 mm
Camera Type	Digital SLR-like camera
