Sony DSC-S780 - 4-1-4. LENS BLOCK

151
152
153
ns
(CCD Assy)
(Note)
ns
ns
(TP1.4X3)
ns
(TP1.4X3)
Note : In case of the CCD assy failure, contact your local Sony
service Headquarter for the measures.
4-1-4. LENS BLOCK
4. REPAIR PARTS LIST
4-4
DSC-S780
Ref. No. Part No. Description
151 A-1557-161-A LENS BLOCK ASSY (SERVICE)
4-110-079-01 FILTER SET, LOW PASS
4-110-078-01 SHEET, BLOCK ASSY PROTECTION
153
152
Ver. 1.1 2008.07
ns : not supplied
