Sony DSC-S780 - Table of Contents

— 4 —
DSC-S780
TABLE OF CONTENTS
1. SERVICE NOTE
1-1. Process After Fixing Flash Error ·····································1-1
1-2. Method for Copying or Erasing the Data in Internal
Memory ···········································································1-1
2. DISASSEMBLY
2-1. Disassembly·····································································2-1
3. BLOCK DIAGRAM
3-1. Overall Block Diagram ···················································3-1
4. REPAIR PARTS LIST
4-1. Exploded Views ·······························································4-1
4-1-1. Overall Section ······························································4-1
4-1-2. Main Frame Block ·························································4-2
4-1-3. Cabinet (Rear) Block ·····················································4-3
4-44-1-4. Lens Block ·····································································
4-2. Accessories ······································································4-5
Section Title Page
The changed portions from
Ver. 1.0 are shown in blue.
Ver. 1.1 2008.07
