Sony DSC-S780 - Page 15

F1
F2
Q13
Ref. No. : F2
MAIN BOARD
【 Regarding Fuse and etc. 】
・
Part No. : 1-576-913-11
Description : FUSE, MICRO (1608 TYPE) (1.6A/36V)
Ref. No. : F1
Part No. : 1-576-363-11
Description : FUSE, MICRO (1005 TYPE) (1A/30V)
Q13 4-120-071-01 DTC144WM3T5G
DSC-S780
The changed portions from
Ver. 1.0 are shown in blue.
Ver. 1.1 2008.07
