HELP
DSC-S780
HELP
Be careful about the Lens Assy.
Attach the Block assy protection sheet as shown.
Don't press the Sensor holder
Don't press the AF Motor
Be careful of the weld
Keep clean these Pins.
Attach the Block assy
protection sheet avoiding
three screw holes.
Attach the Block assy
protection sheet avoiding
four screws.
Block assy
protection sheet
Don't press the Barrier part.
HELP01
HELP02
HELP03
Ver. 1.1 2008.07
