5-5
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DSC-T30_L2
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
BT-030 CD-614 MC-160 RL-068 ST-135
A-1181-188-A BT-030 FLEXIBLE BOARD, COMPLETE
*******************************
< BATTERY TERMINAL >
BH001 1-780-061-11 BATTERY TERMINAL BOARD
< BATTERY >
0* BT002 1-756-566-11 BATTERY, LITHIUM SECONDARY
< DIODE >
* D002 6-501-364-01 DIODE DOR5352
(SELF-TIMER/AF ILLUMINATOR)
< RESISTOR >
R001 1-216-803-11 METAL CHIP 33 5% 1/10W
A-1182-721-A CCD BLOCK ASSY (Note)
(Not supplied) CD-614 FLEXIBLE BOARD, COMPLETE
*******************************
(CD-614 flexible complete board and IC001 are not supplied,
but they are included in CCD block assy.)
< CAPACITOR >
C001 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C003 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C004 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C006 1-100-505-91 CERAMIC CHIP 0.1uF 20% 16V
C007 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
< IC >
IC001 (Not supplied) ICX629EQZ-13 (Note)
IC002 8-753-230-85 IC CXA3691EN-T9
< RESISTOR >
R003 1-218-981-11 RES-CHIP 220K 5% 1/16W
R006 1-218-990-81 SHORT CHIP 0
R007 1-218-976-11 RES-CHIP 82K 5% 1/16W
A-1181-186-A MC-160 FLEXIBLE BOARD, COMPLETE
*******************************
(CN001 (multi connector) and SP901 are not supplied,
but they are included in MC-160 flexible complete board.)
< CONNECTOR >
CN001 (Not supplied) CONNECTOR, MULTIPLE (SOCKET)
< SPEAKER >
SP901 (Not supplied) LOUD SPEAKER (1.3CM)
A-1182-734-A RL BLOCK ASSY
(Not supplied) RL-068 FLEXIBLE BOARD
*********************
(RL-068 flexible board and all mounted parts are not supplied,
but this is included in RL block assy.)
A-1181-185-A ST-135 FLEXIBLE BOARD, COMPLETE
*******************************
0 1-478-621-11 FLASH UNIT
< CAPACITOR >
C001 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C002 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C004 1-100-758-11 CERAMIC CHIP 0.047uF 10% 250V
0* C901 1-114-138-11 ELECT 106uF 315V
< DIODE >
D001 6-501-096-01 DIODE CRF02 (TE85R)
< IC >
IC001 6-707-555-01 IC TPS65552RGTR
< COIL >
* L001 1-400-820-11 INDUCTOR 2.2uH
< TRANSISTOR >
Q001 6-550-656-01 TRANSISTOR CY25BAJ-8F-T23
< RESISTOR >
R002 1-243-975-11 METAL CHIP 4.7M 5% 1/16W
R003 1-208-647-11 METAL CHIP 33 0.5% 1/16W
R004 1-216-121-11 RES-CHIP 1M 5% 1/10W
< TRANSFORMER >
0 T001 1-443-880-11 TRANSFORMER, D.C.-D.C.CONVERTER
Note: Be sure to read “Precautions for Replacement of
Imager” on page 4-3 when changing the imager.
• Refer to page 5-1 for mark 0.
Electrical parts list of the SY-149 board is
not shown.
Pages 5-6 to 5-9 are not shown.
