2-1
DSR-570WS/570WSP V1
Section 2
Service Information
2-1. Location of Major Parts
2-1-1. Location of Major Mechanical Parts
1 Coaster (S)
2 Coaster (T)
3 MIC
4 Reel table (T)
5 Reel plate (T)
6 TL soft brake
7 Sub reel gear (T)
8 Soft brake arm (T)
9 Hard brake arm (T)
0 Pinch arm
!- Shift motor
!= Rail (T)
![ Drum
!] GL (T)
!\ GL (S)
!; C roller
!' Rail (S)
!, Threading gear
!. TC assembly
@/ Cam gear
@- TR arm
@= Reel plate (S)
@[ LD motor
@] No. 1 gear
@\ HC gear
@; Mode gear
@' Release cam gear
@, TR band
@. Sub reel gear (S)
#/ Hard brake arm (S)
#- Soft brake arm (S)
#= Sensor bracket
#[ Reel table (S)
4
5
6
7
8
9
!/
!-
#[
#=
#-
#/
@.
@,
@'
@;
@\
@]
@[
!= ![ !] !\ !; !' !, !. @/ @- @=
32 1
