Quick Start Guide
This guide introduces you to the basic way of recording/playback. See the pages in parentheses
"( )" for more information.
Install the supplied microphone with the model name (ECM-NV1) facing upward. Be sure
to connect the microphone plug to the INPUT1 connector.
to INPUT1
Use the battery pack when using your camcorder outdoors (p. 10).
Connect the plug with its mark
facing toward the LCD panel side.
AC power adaptor (supplied)
Open the DC IN jack
cover.
While pressing r—j
the small blue fOff"
button on the
EJECT switch,
slide it in the direction
of the arrow.
Push the middle
portion of the back of
the cassette to insert it.
Insert the cassette into
the cassette
compartment with the
window facing out
and the write-protect
tab facing upward.
Window
Close the cassette
compartment by
pressing the PUSH
mark on it.
Close the cassette lid
by pressing the
PUSH button on the
cassette lid.
PUSH
Write-protect tab
To Next Page
