Sony DVP-FX921 - Electrical Parts List

9-4E
DVP-FX921/FX921K/FX930/FX930CC/FX930WM/FX935
9-2. ELECTRICAL PARTS LIST
NOTE:
• Duetostandardization,replacementsintheparts
listmaybedifferentfromthepartsspecifiedin
thediagramsorthecomponentsusedontheset.
• -XX and -Xmeanstandardized parts, sothey
mayhavesomedifferencefromtheoriginalone.
• RESISTORS
 Allresistorsareinohms.
 METAL:Metal-filmresistor.
 METALOXIDE:Metaloxide-filmresistor.
 F:nonflammable
• Itemsmarked“*”arenotstockedsincetheyare
seldomrequiredforroutineservice.
 Somedelayshouldbeanticipatedwhenordering
theseitems.
• SEMICONDUCTORS
 Ineachcase,u:µ,forexample:
 uA.. :µA.. uPA.. :µPA..
 uPB.. :µPB.. uPC.. :µPC..
 uPD.. :µPD..
• CAPACITORS
 uF:µF
• COILS
 uH:µH
When indicating parts by reference number,
pleaseincludetheboard.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1703-822-A LCD BOARD, COMPLETE (02-06049311-00) (US)
A-1705-918-A LCD BOARD, COMPLETE (02-06049312-00) (CND)
A-1734-846-A LCD BOARD, COMPLETE (02-06049314-00)
(EXCEPT US, CND)
********************
A-1703-813-A MAIN BOARD, COMPLETE (02-01049301-00) (US)
A-1705-872-A MAIN BOARD, COMPLETE (02-01049302-00)
(CND)
A-1727-419-A MAIN BOARD, COMPLETE (02-01049303-00)
(AEP, UK)
A-1734-838-A MAIN BOARD, COMPLETE (02-01049304-00)
(RUS)
A-1734-839-A MAIN BOARD, COMPLETE (02-01049306-00) (SP)
A-1734-840-A MAIN BOARD, COMPLETE (02-01049307-00) (EA)
*********************
< JACK >
J1 9-885-131-20 DC IN JACK (2N-0003000-M000) (DC IN 9.5V)
J4 9-885-131-19 VIDEO JACK (2N-0002001-FYG0) (VIDEO IN/OUT)
J5 9-885-115-48 USB JACK (2N-0004000-FEX0) (USB)
(EXCEPT US)
J6 9-885-131-18 AUDIO JACK (2N-0003003-FWS0) (AUDIO IN/OUT)
J7 9-885-131-17 PHONE JACK (2N-0005001-FGG0) (PHONES B)
J8 9-885-131-17 PHONE JACK (2N-0005001-FGG0) (PHONES A)
< SWITCH >
SW1 9-885-115-47 SLIDE SW (29-SKYB22D-1000) (POWER ON/OFF)
SW2 9-885-115-47 SLIDE SW (29-SKYB22D-1000) (HOLD .)
MISCELLANEOUS PARTS
   ********************
5 9-885-129-25 LCD SCREEN (AA0900001001)
7 9-885-131-22 10PIN FFC (045-0001-055)
9 9-885-119-28 SPEAKER (570203500-600-G)
0 55 9-885-119-68 TRAVERS (2Q010SQ01-770-G)
MAINLCD
Thecomponentsidentifiedbymark0ordotted
linewithmark0arecriticalforsafety.
Replaceonlywithpartnumberspecified.
Lescomposantsidentifiésparunemarque0
sontcritiquespourlasécurité.
Nelesremplacerqueparunepièceportantle
numérospécifié.
• Abbreviation
 CND :Canadianmodel
 EA :SaudiArabiamodel
 RUS :Russianmodel
 SP :Singaporemodel
