Sony DVP-FX921 - Circuit Voltage Chart

5-3
DVP-FX921/FX921K/FX930/FX930CC/FX930WM/FX935
5-2. CIRCUIT VOLTAGE CHART
U6 (MT1389LP) U6 (MT1389LP) U6 (MT1389LP) U6 (MT1389LP)
PIN STOP (V) PLAY (V) PIN STOP (V) PLAY (V) PIN STOP (V) PLAY (V) PIN STOP (V) PLAY (V)
1 2.038 2.136 33 0.011 0.011 65 2.569 2.504 97 0 0
2 2.039 2.149 34 2.984 2.981 66 1.414 1.435 98 2.867 2.861
3 2.038 2.098 35 3.08 3.077 67 0.018 0.04 99 3.263 3.262
4 2.04 2.13 36 0.128 2.86 68 3.266 3.266 100 3.263 3.262
5 2.033 2.323 37 1.38 1.509 69 0.04 0.05 101 0 0
6 2.032 2.295 38 0.916 0.906 70 0.062 0.05 102 1.259 1.259
7 1.828 1.828 39 1.044 1.044 71 0.04 0.05 103 0 0
8 3.265 3.265 40 3.262 3.262 72 1.759 1.736 104 2.665 2.668
9 0.87 0.769 41 3.263 3.262 73 1.586 1.482 105 3.263 3.262
10 0.831 0.745 42 0.008 0.009 74 1.365 1.435 106 3.263 3.262
11 0 0 43 3.258 3.258 75 3.244 3.2 107 0.388 0.387
12 2.036 2.037 44 2.953 2.953 76 3.113 3.002 108 0.749 0.749
13 1.419 1.418 45 1.294 1.268 77 3.215 3.21 109 0.749 0.747
14 0.587 0.587 46 0.88 0.925 78 3.16 1.78 110 0 0
15 0 0 47 0.843 0.842 79 0 0 111 0.219 0.219
16 0 0 48 0.906 0.98 80 0.915 1.436 112 3.144 3.143
17 3.29 2.231 49 1.167 1.18 81 0.021 0.043 113 0 0
18 3.289 3.261 50 3.266 3.266 82 0.151 0.336 114 3.269 3.267
19 3.265 3.266 51 0.756 0.818 83 1.09 2.36 115 3.269 3.267
20 1.415 1.528 52 0.582
0.645
84 3.266 3.267 116 1.691 1.696
21 1.415 1.389 53 0.817 85 1.003 2.36 117 0 0
22 3.164 3.167 54 1.827 1.827 86 1.013 2.361 118 1.619 1.627
23 3.194 3.195 55 2.932 2.506 87 3.216 3.216 119 1.533 1.559
24 1.396 1.408 56 0.801 0.854 88 3.198 3.198 120 1.574 1.559
25 1.416 1.557 57 1.248 1.435 89 2.651 2.632 121 3.268 3.268
26 0.031 1.892 58 1.315 1.488 90 1.828 1.828 122 3.268 3.268
27 0 0 59 1.241 1.313 91 1.828 1.828 123 1.828 1.828
28 006000920012400
29 3.265 3.265 61 1.065 1.108 93 3.266 3.266 125 0.982 0.981
30 0 0 62 0.958 0.958 94 0 0 126 0.982 1.044
31 0.761 0.762 63 0.854 0.869 95 3.262 3.261 127 1.069 0.945
32 1.825 1.826 64 1.231 1.226 96 0 0 128 1.064 0.965
