VATE
Section
1
OPERATION
1-4-9
BKDS-2050
DSK
With
Border/
FineKey
Board
Contents
DSK-11
board
KPC-6
board
General
Power
requirements
+5
VDC+0.2V
+3.3
VDCL0.2V
Power
consumption:
11
W
maximum
Temperature
range
Storage:
-—20°C
to
+60°C
(-4°F
to
+140°F)
Operation
guaranteed:
5°C
to
40°C
(41°F
to
104°F)
Performance
guaranteed:
10°C
to
35°C
(50
°Fto
95°F)
Dimensions
(excluding
projections)
DSK-11:75
x
20
x190
mm
(
3x!/16
x7
'/2
inches)
(whh/d)
KPC-6:
32020220
mm
(12
5/gx¥/16x
15
3/sinches)
(w/h/d)
Mass
DSK-11:
0.1L
kg
KPC-6:
1.3
kg
Other
Functions
Key
border
generator
Matte
generator
(for
fill
and
edge)
Mask
generators
1-4-10
BKDS-2060
Assignable
Output
Board
General
Power
requirements:
+5
V
DC+0.2
V
Power
consumption:
10
W
maximum
-
Temperature
range
Storage:
-20°C
to
+60°C
(-4°F
to
+140°F)
Operation
guaranteed:
5°C
to
40°C
(41°F
to
104°F)
Performance
guaranteed:
10°C
to
35°C
(50°F
to
95
°F)
Dimensions
(excluding
projections)
320x20x135mm
(12
5/s
x
13/16
x
5
3/s
inches)
(w/h/d)
Mass:
0.4
kg
(14
oz)
