Sony DVW-2000P - 2-1-2 Lower Control Panel

Chapter 2 Location and Function of Parts
Chapter 2 Location and Function of Parts 2-3
VID. IN PB/EE CONFI CTL/TC
Y-R,B
PB
OFF TC
MENU
TCGSET
VID. IN PB/EE CONFI CTL/TC
Y-R,B
PB
OFF TC
MENU
TCGSET
1 Audio control section
(see page 2-4)
2 CHANNEL CONDITION
indicator (see page 2-6)
3 Menu control buttons
(see page 2-6)
4 Time data/menu display section (see page 2-7)
5 MULTI CONTROL knob and SHIFT
indicator (see page 2-8)
6 RESET button (see page 2-8)
7 Search control section (see page 2-8)
9 Tape transport control section (see page 2-10)
q; Editing mode setting
section (see page 2-11)
qa ALARM indicator and KEY INHI
indicator (see page 2-11)
qd Editing control section (see page 2-12)
qf Shot mark section (see page 2-13)
8 REC INHI indicator (see page 2-10)
qs PLAYER button and RECORDER
button (see page 2-12)
2-1-2 Lower Control Panel
