3-2 Reference Signals for Video Output and Servo System
Chapter 3 Preparations
3-6 Chapter 3 Preparations
Connections for playback
• SDI OUTPUT
• COMPOSITE
• COMPONENT
REF. VIDEO
INPUT
75Ω 75Ω
Reference signal
Video monitor
DVW-M2000/M2000P/2000/2000P
75 Ω termination switch: ON
