Sony DVW-M2000 - Switch Panel Settings

A-2
HDW-2000/M2000/M2000P/S2000/S2000P/M2100/M2100P, DVW-2000/2000P/M2000/M2000P
MSW-2000/A2000/A2000P/M2000/M2000P/M2000E/M2000EP/M2100/M2100P/M2100E/M2100EP
m
. The [R] marked setting is for recorder only.
. All the board, switch, and menu are described. Some of them are not used in your model.
Connector panel
Switch Factory setting Setting
[R] Analog audio input level CH1 HIGH ON [||] LOW [||] HIGH OFF [||] HIGH ON
600 Z
CH2 HIGH ON
[||] LOW [||] HIGH OFF [||] HIGH ON
CH3 HIGH ON [||] LOW [||] HIGH OFF [||] HIGH ON
CH4 HIGH ON [||] LOW [||] HIGH OFF [||] HIGH ON
Reference video input 75 Z ON [||] ON [||] OFF
[R] Composite video input 75 Z ON [||] ON [||] OFF
Upper control panel
Switch Factory setting Setting
REMOTE 1 (9P) LOCAL [||] Lighting (REMOTE) [||] Lightless (LOCAL)
REMOTE 2 (50P) LOCAL [||] Lighting (REMOTE) [||] Lightless (LOCAL)
NETWORK DISABLE [||] Lighting (ENABLE) [||] Lightless (DISABLE)
Lower control panel
Switch Factory setting Setting
DISPLAY FULL/FINE FULL [||] FULL [||] FINE
[R] AUDIO MIXING CH-1 NOT MIX [||] NOT MIX [||] MIX
[
[||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
]
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
CH-2 NOT MIX [||] NOT MIX [||] MIX
[
[||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
]
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
CH-3 NOT MIX [||] NOT MIX [||] MIX
[
[||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
]
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
CH-4 NOT MIX [||] NOT MIX [||] MIX
[
[||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
]
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
CH-5 NOT MIX [||] NOT MIX [||] MIX
[
[||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
]
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
CH-6 NOT MIX [||] NOT MIX [||] MIX
[
[||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
]
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
CH-7 NOT MIX [||] NOT MIX [||] MIX
[
[||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
]
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
CH-8 NOT MIX [||] NOT MIX [||] MIX
[
[||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
]
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
[R] AUDIO INPUT CH-1 ANALOG [||] SDI [||] AES/EBU [||] ANALOG
CH-2 ANALOG [||] SDI [||] AES/EBU [||] ANALOG
CH-3 ANALOG [||] SDI [||] AES/EBU [||] ANALOG
CH-4 ANALOG [||] SDI [||] AES/EBU [||] ANALOG
CH-5 AES/EBU [||] SDI [||] AES/EBU
CH-6 AES/EBU [||] SDI [||] AES/EBU
CH-7 AES/EBU [||] SDI [||] AES/EBU
CH-8 AES/EBU [||] SDI [||] AES/EBU
AUDIO MONITOR L CH-1 only [||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
[||] CUE
R CH-2 only [||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
[||] CH-5 [||] CH-6 [||] CH-7 [||] CH-8
[||] CUE
Setting Check Sheet
