A-3
HDW-2000/M2000/M2000P/S2000/S2000P/M2100/M2100P, DVW-2000/2000P/M2000/M2000P
MSW-2000/A2000/A2000P/M2000/M2000P/M2000E/M2000EP/M2100/M2100P/M2100E/M2100EP
Switch panel
Switch Factory setting Setting
PANEL SELECT FRONT [||] FRONT [||] REAR
KEY INHIBIT OFF [||] ON [||] OFF
Switches on the board
n
Never change the setting of Factory use switches.
Board Name Channel Switch No. Factory setting Setting
APR-52 [R] Audio input level CH1 S100 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
CH2 S200 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
CH3 S300 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
CH4 S400 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
Audio input headroom CH1 S101 20 dB [||] 20 [||] 18 [||] 16 [||] 12
CH2 S201 20 dB [||] 20 [||] 18 [||] 16 [||] 12
CH3 S301 20 dB [||] 20 [||] 18 [||] 16 [||] 12
CH4 S401 20 dB [||] 20 [||] 18 [||] 16 [||] 12
Audio output level CH1 S501 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
CH2 S601 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
CH3 S701 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
CH4 S801 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
Audio output headroom CH1 S500 20 dB [||] 20 [||] 18 [||] 16 [||] 12
CH2 S600 20 dB [||] 20 [||] 18 [||] 16 [||] 12
CH3 S700 20 dB [||] 20 [||] 18 [||] 16 [||] 12
CH4 S800 20 dB [||] 20 [||] 18 [||] 16 [||] 12
Monitor output level L S902 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
R S1002 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
Monitor output headroom L S900 20 dB [||] 20 [||] 18 [||] 16 [||] 12
R S1000 20 dB [||] 20 [||] 18 [||] 16 [||] 12
Monitor output level L S901 Fixed (UNITY) [||] Fixed [||] Variable
FIXED/VARIABLE switch
R S1001 Fixed (UNITY) [||] Fixed [||] Variable
AE-31 HEAD TUNE switch CH1 S100 Factory use _
CH2 S200 Factory use _
AU-272 Analog audio (LAU) CH1 S101 0 dB [||] 0 [||] +3
(Suffix -12 output level
CH2 S201 0 dB [||] 0 [||] +3
and higher)
Analog audio (AFM) CH3 S600 0 dB [||] 0 [||] +3
output gain
CH4 S700 0 dB [||] 0 [||] +3
CUE-13 [R] CUE audio input level _ S100 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
CUE audio output level _ S101 +4 dBm/600 Z [||] +4 [||] 0 [||] _3 [||] _20
Setting Check Sheet
