A-7
HDW-2000/M2000/M2000P/S2000/S2000P/M2100/M2100P, DVW-2000/2000P/M2000/M2000P
MSW-2000/A2000/A2000P/M2000/M2000P/M2000E/M2000EP/M2100/M2100P/M2100E/M2100EP
Function menu Setting
Page Button Name Factory setting Setting
HOME1 [R] F1 VID.IN SDI [||] SDI [||] SDTI [||] COMPST [||] Y, R/B
[R] F2 PB/EE EE [||] EE [||] PB
[R] F3 CONFI DISABLE [||] ENABLE [||] DISABLE
F4 CTL/TC TC [||] TC [||] UB [||] CTL
F5 MENU __
[R] F6 TCGSET __
Page1 [R] F1 TCG INT [||] INT [||] EXT [||] SDI
(HDW
[R] F2 PR/RGN PRESET [||] PRESET [||] LTC [||] VITC
series)
[R] F3 RUN REC [||] REC [||] FREE
F4 DF DF [||] DF [||] NDF
F5 _
F6 TCR AUTO [||] LTC [||] AUTO [||] VITC
Page1 [R] F1 TCG INT [||] INT [||] EXT [||] RP188 [||] CP-LTC
*1
(DVW/
[R] F2 TCG PRESET [||] PRESET [||] REGEN
MSW
[R] F3 RUN REC [||] REC [||] FREE
series)
F4 DF
*2
DF [||] DF [||] NDF
[R] F5 VITC ON [||] ON [||] OFF
F6 TCR AUTO [||] LTC [||] AUTO [||] VITC
Page2 F1 V.PROC LOCAL [||] LOCAL [||] REMOTE [||] MENU
F2 VIDEO PRESET [||] PRESET [||] VALUE: _______
F3 CHROMA PRESET [||] PRESET [||] VALUE: _______
F4
*3
HUE/C PHAS PRESET [||] PRESET [||] VALUE: _______
F5
*3
SETUP/BLACK PRESET [||] PRESET [||] VALUE: _______
F6 YC DLY PRESET [||] PRESET [||] VALUE: _______
Page3 F1 SYNC 0 VALUE: _______
F2 SC 0 VALUE: _______
[R] F3 VIN LV AGC [||] AGC [||] VALUE: _______
F4 EMPHSS OFF [||] ON [||] OFF
F5 T INFO TOTAL [||] TOTAL [||] REMAIN
Page4 F1 CAPSTN 4F [||] 2F [||] 4F [||] 8F
[R] F2 OUTREF INPUT [||] INPUT [||] REF
F3 DOLBY NR OFF [||] NR ON [||] NR OFF
F4 CHARA ON [||] ON [||] OFF
F5 RECINH OFF [||] ON [||] OFF
[R] F6 PREREAD OFF [||] ON [||] OFF
HOME2
*4
F1 [ ] NONE [ ]
F2 [ ] NONE [ ]
F3 [ ] NONE [ ]
F4 [ ] NONE [ ]
F5 [ ] NONE [ ]
F6 [ ] NONE [ ]
*1: DVW series does not have this item.
*2: For 525 mode. Does not indicated in 625 mode.
*3: The name is different between 525/59.94 Hz mode and 625/50 Hz mode.
*4: HOME2 is programmable at user side. Nothing is assigned to it at exfactory.
Setting Check Sheet
