A-6
HDW-2000/M2000/M2000P/S2000/S2000P/M2100/M2100P, DVW-2000/2000P/M2000/M2000P
MSW-2000/A2000/A2000P/M2000/M2000P/M2000E/M2000EP/M2100/M2100P/M2100E/M2100EP
Setting Check Sheet
(Continued)
Board Switch No. : Name Factory setting Setting
VN-13 S101 1 - 3 : Factory use OFF _
(Suffix -13
4 : Function select
*
OFF
and higher)
5 - 8 : Factory use OFF _
S102 1, 2 : Factory use OFF _
*: Select the function only when the EPR-1 board number suffix is -12 or -13.
To Next Page
