Command List
FCB-EH3400/EH3300(GB) A-E4D-100-13(1)
Command List (5/5)
Command Set Command Command Packet Comments
CAM_IDWrite — 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000 to FFFF)
CAM_Alarm On 8x 01 04 6B 02 FF Alarm ON/OFF
Off 8x 01 04 6B 03 FF
SetMode 8x 01 04 6C pp FF pp: Mode setting
00 Focus change detection
(reference value is not updated)
01 Focus change detection (reference value is updated)
02 AE change detection (reference value is not updated)
03 AE change detection (reference value is updated)
SetDayNighLevel 8x 01 04 6D 0p 0p 0p 0q 0q 0q FF ppp: Day judgement level setting
qqq: Night judgement level setting
Alarm(Reply) y0 07 04 6B 01 FF
Detection level “Low”  “High”
y0 07 04 6B 00 FF
Detection level “High”
 “Low”
CAM_MD On 8x 01 04 1B 02 FF Motion Detection On/Off
Off 8x 01 04 1B 03 FF
Function Set 8x 01 04 1C 0m 0n 0p 0q 0r 0s FF m: Display mode
n: Detection Frame Set (0 to F)
pq: Threshold Level (00 to FF)
rs: Interval Time set (00 to FF)
Window Set 8x 01 04 1D 0m 0p 0q rr 0s FF m: Select Detection Frame (0, 1, 2, 3)
p: Start Horizontal Position (00 to 0F)
q: Start Vertical Position (00 to 07)
r: Stop Horizontal Position (01 to 10)
s: Stop Vertical Position (01 to 08)
Alarm (Reply) y0 07 04 1B 0p FF p: Detection Frame Number
CAM_Continuous
ZoomPosReply
On 8x 01 04 69 02 FF ZoomPosition data Continuous Output On/Off
Off 8x 01 04 69 03 FF
(Reply) y0 07 04 69 0p 0p 0q 0q 0q 0q FF pp: D-Zoom Position
* 00: When Zoom Mode is Combine
qqqq: Zoom Position
CAM_
ReplyIntervalTimeSet
— 8x 01 04 6A 00 00 0p 0p FF pp: Interval Time [Vertical timing]
CAM_RegisterValue — 8x 01 04 24 mm 0p 0p FF mm: Register No. (=00-7F)
pp: Register Value (=00-7F)
CAM_ColorEnhance Parameter Set 8x 01 04 20 mm nn
pp qq rr FF
mm: First byte from the top threshold value
nn: Second byte from the top threshold value
pp: Third byte from the top threshold value
qq: Color specification for high-intensity
rr: Color specification for low-intensity
Range for mm, nn, and pp is 0 to F.
Range for qq and rr is 0 to 8.
Colors
0: Yellow, 1: Cyan, 2: Green, 3: White, 4: Magenta,
5: Red, 6: Blue, 7: Black, 8: Gray
On 8x 01 04 50 02 FF Color Enhancement ON/OFF
Off 8x 01 04 50 03 FF
CAM_ChromaSuppress 8x 01 04 5F pp FF pp: Chroma Suppress setting level
00: OFF
1 to 3: ON (3 levels).
Effect increases as the level number increases.
CAM_ColorGain Direct 8x 01 04 49 00 00 00 0p FF p: Color Gain setting 0h (60%) to Eh (200%)
CAM_ColorHue Direct 8x 01 04 4F 00 00 00 0p FF p: Color Hue setting 0h (− 14 dgrees) to Eh ( +14 degrees)
