Command List
FCB-EH3400/EH3300(GB) A-E4D-100-13(1)
Temperature Reading Conversion Value
(Reference Value)
Reading Value
pq (hex)
Temperature
Conversion
Value (ºC)
00 −3 to +3
0A 7 to 13
14 17 to 23
1E 27 to 33
28 37 to 43
32 47 to 53
3C 57 to 63
Register Setting
The register settings are enabled when the power is
turned off and then back on again. After turning the
power back on again, verify that the mode settings have
been changed.
Register No. Value
VISCA
Baud Rate
00 00
(Default value)
9600 bps
01 19200 bps
02 38400 bps
Monitoring
Mode
72 09
(Default value)
720p/60
0A 720p/59.94
0B NTSC Analog Output
(Stop Digital Output)
0C 720p/50
0D PAL Analog Output
(Stop Digital Output)
0E 720p/30
0F 720p/29.97
10 NTSC Analog Output
(Stop Digital Output)
11 720p/25
12 PAL Analog Output
(Stop Digital Output)
Output
Enabling
73 01 Analog Output
enabled
02 Digital Output
enabled
03
(Default value)
Both Analog/Digital
Output enabled
Zoom Limit
50 00-FF
(Default value: 00)
Wide Limit
(0: Disabled)
51 00-FF
(Default value: 00)
Tele Limit
(0: Disabled)
E-Zoom Max
52 00-EB
(Default value: EB)
Max. digital
zoom ratio =
256 ÷ (256-Value)
StableZoom 53 00
(Default value: 00)
OFF
01 ON
FocusTrace
@ZoomDirect
54 00 OFF
01
(Default value: 01)
ON
FocusOffset
@DomeCover
55 00-FF
(Default value: 00)
00: None to
FF: Max.
SAV/EAV 56 00
(Default value: 00)
OFF
FCB-EH3300/EH3310
Wide/Tele Limit
Setting Value
Wide Limit Tele Limit
Zoom
Position
Zoom
Ratio
Zoom
Position
Zoom
Ratio
00 0000 1.00 4000 20.0
10 0161 1.03 3E9E 17.3
20 02C3 1.07 3D3C 15.4
30 0425 1.11 3BDA 14.0
40 0587 1.15 3A78 12.7
50 06E9 1.19 3916 11.6
60 084B 1.23 37B4 10.6
70 09AD 1.28 3652 9.7
80 0B0E 1.33 34F1 8.9
90 0C70 1.39 338F 8.1
A0 0DD2 1.44 322D 7.4
B0 0F34 1.51 30CB 6.8
C0 1096 1.57 2F69 6.2
D0 11F8 1.64 2E07 5.7
E0 135A 1.72 2CA5 5.3
F0 14BB 1.80 2B44 4.9
FF 1607 1.88 29F8 4.5
Title setting
Line number 00 to 0A
H-position 00 to 1F
Blink
00: Dose not blink
01: Blinks
Color
00 White
01 Yellow
02 Violet
03 Red
04 Cyan
05 Green
06 Blue
00 01 02 03 04 05 06 07
A B C D E F G H
08 09 0a 0b 0c 0d 0e 0f
I J K L M N O P
10 11 12 13 14 15 16 17
Q R S T U V W X
18 19 1a 1b 1c 1d 1e 1f
Y Z & ? ! 1 2
20 21 22 23 24 25 26 27
3 4 5 6 7 8 9 0
28 29 2a 2b 2c 2d 2e 2f
À È Ì Ò Ù Á É Í
30 31 32 33 34 35 36 37
Ó Ú Â Ê Ô Æ Ã
38 39 3a 3b 3c 3d 3e 3f
Õ Ñ Ç ß Ä Ï Ö Ü
40 41 42 43 44 45 46 47
Å $ ¥ £ ¿ ¡
48 49 4a 4b 4c 4d 4e 4f
ø “ : ‘ . , / -
