Sony FCB-EH3300 - Digital Zoom Modes; Lens Control Settings

49
Command List
FCB-EH3400/EH3300(GB) A-E4D-100-13(1)
Digital Zoom Combine mode
X12
Digital Zoom
Ratio
Digital Zoom
Position Data
×1 4000
×2 6000
×3 6A80
×4 7000
×5 7300
×6 7540
×7 76C0
×8 7800
×9 78C0
×10 7980
×11 7A00
×12 7AC0
Digital Zoom Separate mode
X12
Digital Zoom
Ratio
Digital Zoom
Position Data
×1 00
×2 80
×3 AA
×4 C0
×5 CC
×6 D5
×7 DB
×8 E0
×9 E3
×10 E6
×11 E8
×12 EB
Lens control
Zoom Position
0000 to 4000 to 7AC0
Wide end Optical Digital
Tele end Tele end
Focus Position
1000 to C000
Far end Near end
Focus Near
Limit
1000: Over Inf
2000: 12m
3000: 5.6m
4000: 4m
5000: 2.7m
6000: 2m
7000: 1.5m
8000: 80cm
9000: 30cm
(initial setting)
A000: 19cm
B000: 9cm
C000: 1cm
As the distance on the left
will differ due to temperature
characteristics, etc., use as
approximate values.
* The lower 1 byte is fixed at 00.
Wide/Tele Limit Setting
FCB-EH3400/EH3410
Wide/Tele Limit
Setting Value
Wide Limit Tele Limit
Zoom
Position
Zoom
Ratio
Zoom
Position
Zoom
Ratio
00 0000 1.00 4000 28.0
10 0161 1.04 3E9E 22.8
20 02C3 1.08 3D3C 19.8
30 0425 1.12 3BDA 17.6
40 0587 1.17 3A78 15.9
50 06E9 1.21 3916 14.4
60 084B 1.27 37B4 13.1
70 09AD 1.32 3652 11.9
80 0B0E 1.38 34F1 10.8
90 0C70 1.44 338F 9.8
A0 0DD2 1.51 322D 8.9
B0 0F34 1.58 30CB 8.1
C0 1096 1.66 2F69 7.4
D0 11F8 1.74 2E07 6.8
E0 135A 1.83 2CA5 6.2
F0 14BB 1.92 2B44 5.7
FF 1607 2.02 29F8 5.3
