Exposure control (2/2)

IRIS GAIN

Bright

1F F1.35 +28 dB

1E F1.35 +26 dB

1D F1.35 +24 dB

1C F1.35 +22 dB

1B F1.35 +20 dB

1A F1.35 +18 dB

19 F1.35 +16 dB

18 F1.35 +14 dB

17 F1.35 +12 dB

16 F1.35 +10 dB

15 F1.35 +8 dB

14 F1.35 +6 dB

13 F1.35 +4 dB

12 F1.35 +2 dB

11 F1.35 0 dB

10 F1.6 0 dB

0F F2 0 dB

0E F2.4 0 dB

0D F2.8 0 dB

0C F3.4 0 dB

0B F4 0 dB

0A F4.8 0 dB

09 F5.6 0 dB

08 F6.8 0 dB

07 F8 0 dB

06 F9.6 0 dB

05 F11 0 dB

04 F14 0 dB

03 F16 0 dB

00 CLOSE 0 dB

Exposure Comp.

0E +7 +10.5 dB

0D +6 +9 dB

0C +5 +7.5 dB

0B +4 +6 dB

0A +3 +4.5 dB

09 +2 +3 dB

08 +1 +1.5 dB

07 0 0 dB

06 −1 −1.5 dB

05 −2 −3 dB

04 −3 −4.5 dB

03 −4 −6 dB

02 −5 −7.5 dB

01 −6 −9 dB

00 −7 −10.5 dB

Zoom Ratio and Zoom Position

(for reference)

FCB-EH3400/EH3410

Zoom Ratio

×28 Lens

Optical Zoom

Positon Data

×1 0000

×2 15CA

×3 1F65

×4 2527

×5 2921

×6 2C22

×7 2E88

×8 3088

×9 3242

×10 33C9

×11 3529

×12 366C

×13 3795

×14 38A8

×15 39A5

×16 3A8E

×17 3B61

×18 3C1E

×19 3CC7

×20 3D5C

×21 3DDE

×22 3E50

×23 3EB3

×24 3F09

×25 3F53

×26 3F94

×27 3FCD

×28 4000

FCB-EH3300/EH3310

Optical Zoom

Ratio ×20 Lens

Optical Zoom

Position Data

×1 0000

×2 17C5

×3 21CD

×4 27B5

×5 2BC4

×6 2ED4

×7 314A

×8 335C

×9 352B

×10 36C8

×11 383E

×12 3994

×13 3ACB

×14 3BE3

×15 3CDB

×16 3DB3

×17 3E6C

×18 3F0A

×19 3F8F

×20 4000
