Sony FCB-EH3300 - Locations of Controls

5
Locations of Controls
FCB-EH3400/EH3300(GB) A-E4D-100-13(1)
Locations of Controls
 Lens
 CN501 jack
 CN601 jack
 Tripod screw hole
When a tripod is used, please use 7 mm (
9
/
32
in.) or less screw to attach it to the camera.
Also, please be sure to attach the tripod securely.
Front Back Bottom
Front Back Bottom
FCB-EH3400/EH3410
FCB-EH3300/EH3310
