Command List
FCB-EH3400/EH3300(GB) A-E4D-100-13(1)
Inquiry Command List (3/3)
Inquiry Command Command Packet Inquiry Packet Comments
CAM_MuteModeInq 8x 09 04 75 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_PrivacyDisplayInq 8x 09 04 77 FF y0 50 pp pp pp pp FF pp pp pp pp: Mask Display (0: OFF, 1: ON)
CAM_PrivacyPanTiltInq 8x 09 04 79 FF y0 50 0p 0p 0p 0q 0q 0q FF ppp: Pan
qqq: Tilt
CAM_PrivacyPTZInq 8x 09 04 7B mm FF y0 50 0p 0p 0p 0q 0q 0q 0r 0r 0r 0r
FF
mm: Mask Settings
ppp: Pan
qqq: Tilt
rrr: Zoom
CAM_PrivacyMonitorInq 8x 09 04 6F FF y0 50 pp pp pp pp FF pp pp pp pp: Mask is displayed now.
CAM_KeyLockInq 8x 09 04 17 FF y0 50 00 FF Off
y0 50 02 FF
On
CAM_IDInq 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs: Camera ID
CAM_VersionInq 8x 09 00 02 FF y0 50 00 20
mn pq rs tu vw FF
mnpq: Model Code (04xx)
rstu: ROM version
vw: Socket Number (=02)
CAM_AlarmInq 8x 09 04 6B FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_AlarmModeInq 8x 09 04 6C FF y0 50 pp FF pp: Alarm Mode
CAM_AlarmDayNightLevelInq 8x 09 04 6D FF y0 50 0p 0p 0p
0q 0q 0q 0r 0r 0r FF
ppp: Day judgement level setting
qqq: Night judgement level setting
rrr: Current Automatic Exposure level setting
CAM_AlarmDetectLevelInq 8x 09 04 6E FF y0 50 01 FF Detection level “High”
y0 50 00 FF Detection level “Low”
CAM_MDModeInq 8x 09 04 1B FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_MDFunctionInq 8x 09 04 1C FF y0 50 0m 0n 0p 0q FF m: Display mode
n: Detection Frame Set (0 to F)
pq: Threshold Level (0 to FF)
rs: Interval Time set (0 to FF)
CAM_MDWindowInq 8x 09 04 1D 0m FF y0 50 0p 0q 0r 0s FF m: Select Detection Frame (0, 1, 2, 3)
p: Start Horizontal Position (00 to 0B)
q: Start Vertical Position (00 to 07)
r: Stop Horizontal Position (01 to 0C)
s: Stop Vertical Position (01 to 08)
CAM_ContinuousZoomPos
ReplyModeInq
8x 09 04 69 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_ReplyIntervalTimeInq 8x 09 04 6A FF y0 50 00 00 0p 0p FF pp: Interval Time
CAM_RegisterValueInq 8x 09 04 24 mm FF y0 50 0p 0p ff mm: Register No. (00 to 7F)
pp: Register Value (00 to FF)
CAM_ColorEnhanceInq 8x 09 04 20 FF y0 50 mm nn pp qq rr FF mm: First byte from the top threshold value
nn: Second byte from the top threshold value
pp: Third byte from the top threshold value
qq: Color specification for high-intensity
rr: Color specification for low-intensity
Colors
0: Yellow, 1: Cyan, 2: Green, 3: White,
4: Magenta, 5: Red, 6: Blue, 7: Black, 8: Gray
8x 09 04 50 FF y0 50 02 FF
On
y0 50 03 FF
Off
CAM_ChromaSuppressInq 8x 09 04 5F FF y0 50 pp FF pp: Chroma Suppress setting level
CAM_ColorGainInq 8x 09 04 49 FF y0 50 00 00 00 0p FF p: Color Gain setting 0h (60%) to Eh (200%)
CAM_ColorHueInq 8x 09 04 4F FF y0 50 00 00 00 0p FF p: Color Hue setting 0h (− 14 degrees) to Eh (+ 14 degrees)
CAM_TempInq 8x 09 04 68 FF Y0 50 00 00 0p 0q FF pq: Temperature *Lens temperature
