Command List
Inquiry Command List (3/4)
Inquiry Command Command Packet Inquiry Packet Comments
CAM_PrivacyPanTiltInq 8x 09 04 79 FF y0 50 0p 0p 0p 0q 0q 0q FF ppp: Pan
qqq: Tilt
CAM_PrivacyPTZInq 8x 09 04 7B mm FF y0 50 0p 0p 0p 0q 0q 0q 0r 0r mm: Mask Settings
0r 0r FF ppp: Pan
qqq: Tilt
rrr: Zoom
CAM_PrivacyMonitorInq 8x 09 04 6F FF y0 50 pp pp pp pp FF pp pp pp pp: Mask is displayed now.
CAM_KeyLockInq 8x 09 04 17 FF y0 50 00 FF Off
y0 50 02 FF On
CAM_IDInq 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs: Camera ID
CAM_MemSaveInq 8x 09 04 23 0X FF y0 50 0p 0p 0q 0q FF X: 00 to 07 (Address)
ppqq: 0x0000 to 0xFFFF (Data)
CAM_ExtLockInq 8x 09 04 55 FF y0 50 00 FF Internal Sync
y0 50 01 FF V-Phase Adjustment
y0 50 02 FF External Sync
CAM_VPhasePosInq 8x 09 04 45 FF y0 50 0p 0q 0r 0s FF pqrs: V-Phase Position
CAM_VersionInq 8x 09 00 02 FF y0 50 00 20 mnpq: Model Code (04xx)
mn pq rs tu vw FF rstu: ROM version
vw: Socket Number (=02)
CAM_AlarmInq 8x 09 04 6B FF y0 50 02 FF On
y0 50 03 FF Off
CAM_AlarmModeInq 8x 09 04 6C FF y0 50 pp FF pp: Alarm Mode
CAM_AlarmDayNightLevelInq 8x 09 04 6D FF y0 50 0p 0p 0p ppp: Day judgement level setting
0q 0q 0q 0r 0r 0r FF qqq: Night judgement level setting
rrr: Current Automatic Exposure level setting
CAM_AlarmDetectLevelInq 8x 09 04 6E FF y0 50 01 FF Detection level “High”
y0 50 00 FF Detection level “Low”
CAM_MDModeInq 8x 09 04 1B FF y0 50 02 FF On
y0 50 03 FF Off
CAM_MDFunctionInq 8x 09 04 1C FF y0 50 0m 0n 0p 0q FF m: Display mode
n: Detection Frame Set (0 to F)
pq: Threshold Level (0 to FF)
rs: Interval Time set (0 to FF)
CAM_MDWindowInq 8x 09 04 1D 0m FF y0 50 0p 0q 0r 0s FF m: Select Detection Frame (0, 1, 2, 3)
p: Start Horizontal Position (00 to 0B)
q: Start Vertical Position (00 to 07)
r: Stop Horizontal Position (01 to 0C)
s: Stop Vertical Position (01 to 08)
CAM_ContinuousZoomPos 8x 09 04 69 FF y0 50 02 FF On
ReplyModeInq y0 50 03 FF Off
CAM_ReplyIntervalTimeInq 8x 09 04 6A FF y0 50 00 00 0p 0p FF pp: Interval Time
CAM_RegisterValueInq 8x 09 04 24 mm FF y0 50 0p 0p ff mm: Register No. (00 to 7F)
pp: Register Value (00 to FF)
