Sony FCB-EX1020 - Page 61

61
Specifications
FCB-EX1020P
Digital Output Timing [50p mode]
Data out [0-7]
CLK [56.75 MHz]
Horizontal
Vertical
Data out [0-7]
4CLK
SAV
4CLK
BLK
4CLK
BLK
1504CLK Effective pixel
1H = 1816CLK
4CLK
EAV
304CLK
BLK
625H
24H
BLK
582H Effective line
BLK : Black data (Y 10, Cb/Cr 80)
19H2H
BLK
Cr0 Y1
Cb0
Y0 Cr1 Y3
Cb1
Y2
Cr
Y Cb Y Cr Y Cb Y
BLK
FCB-EX1020P
Digital Output Timing [25p mode]
Data out [0-7]
CLK [28.375 MHz]
Horizontal
Vertical
Data out [0-7]
4CLK
SAV
4CLK 4CLK
BLK BLK
1504CLK Effective pixel
1H = 1816CLK
4CLK
EAV
304CLK
BLK
625H
24H
BLK
582H Effective line
19H
BLK
2H
BLK : Black data (Y 10, Cb/Cr 80)
Cr0 Y1
Cb0
Y0 Cr1 Y3
Cb1
Y2 Cb
Cr
Y Y Cr Y Cb Y
BLK
