SMART CORE STRUCTURE
1. Disassemble COVER TOP
Pull up the cover top by the following order.
2. Disassemble MIC FPC
Pull up the cover top by the following order.
3. Disassemble H board
Hold this area and pick up H board
Pull up and Slide
Connector pull up and FPC slide
1
2
3
1
2
