63
HCD-DZ230/DZ231/HDZ235
Pin No. Pin Name I/O Description
48 RESERVED — USB port DMINUS pin for HS DL (not used (Open))
49 USB_VDD3 — Power supply (SW+3.3V)
50 SPFG I Spindle FG input
51 MSW O DVD/CD switch (H:DVD / L:CD)
52 CKSW I CKSW input
53 OCSW I OCSW input
54 EEWP O EEPROM Write Protect control (L:Write allowed)
55 DVDD18 — Power supply (+1.8V from IC1110)
56 to 64 HA2 to 8, 18, 19 O Host address bus 2 to 8, 18, 19 output to Flash ROM (IC1102)
65 DVDD3 — Power supply (SW+3.3V)
66 XWR O Write enable output to Flash ROM (IC1102) (active Low)
67 to 75 HA16 to 9, 20 O Host address bus 15 to 9, 20 output to Flash ROM (IC1102)
76 XROMCS O Chip select output to Flash ROM (IC1102) (active Low)
77 HA1 O Host address bus 1 output to Flash ROM (IC1102)
78 XRD O Read enable output to Flash ROM (IC1102) (active Low)
79, 80 HD0,1 I/O Host data bus 0,1 input/output for Flash ROM (IC1102)
81 DVSS — Ground terminal
82 to 86 HD2 to 6 I/O Host data bus 2 to 6 input/output for Flash ROM (IC1102)
87 HA21 O Host address bus 21 output to Flash ROM (IC1102)
88 RESERVED — Not used (Open)
89 HD7 I/O Host data bus 7 input/output for Flash ROM (IC1102)
90 DVSS — Ground terminal
91, 92 HA17, 0 O Host address bus 17, 0 output to Flash ROM (IC1102)
93 DVDD18 — Power supply (+1.8V from IC1110)
94 RESERVED — Not used (Open)
95 RESERVED — Not used (Open)
96 DVDD3 — Power supply (SW+3.3V)
97 IFSDO O Ext. CPU Serial data output (H/W method)
98 IFCK O Ext. CPU Serial clock (H/W method)
99 xIFCS O Chip select for Ext.CPU (Low Active, H/W method)
100 IFSDI I Ext. CPU Serial data input (H/W method)
101 SCL O IIC clock output to E2PROM and HDMI controller
102 SDA I/O IIC data input/output for E2PROM and HDMI controller
103 HDMI_SCL O HDMI DDC line SCL
104 HDMI_SDA I/O HDMI DDC line SDA
105 RXD I RS232C RXD signal input from Jig
106 TXD O RS232C TXD signal output to Jig
107 ICE O ICE mode enable (not used (Open))
108 xSYSRST I Reset input from system controller (IC501) (active Low)
109 RESERVED I IR control signal input (not used (Open))
110 xTXINT I Interrupt signal from HDMI controller (not used (Fixed “H” (SW+3.3V)))
111 DQM0 O Lower byte mask output to SDRAM (IC1104) (H:Mask / L:Enable)
112 IFBSY I Ready/Busy interrupt signal input from system controller (IC501) (H:Busy / L:Ready)
113 to 117 RD7 to 3 I/O Data bus 7 to 3 input/output for SDRAM (IC1104)
118 DVDD3 — Power supply (SW+3.3V)
119 to 129 RD2 to 0, 15 to 8 I/O Data bus 2 to 0, 15 to 8 input/output for SDRAM (IC1104)
130 LIMITSW I LIMITSW signal input
131 DVDD3 — Power supply (SW+3.3V)
132 DQM1 O Upper byte mask output to SDRAM (IC1104) (H:Mask / L:Enable)
