65
HCD-DZ230/DZ231/HDZ235
Pin No. Pin Name I/O Description
198 TRG_SW I Slot-in MECHA Triger SW detect (not used (Fixed to “H” (SW+3.3V)))
199 SCORE I Calculation of SCORE (not used (Fixed to Ground))
200 XVOICE I
Detection of MIC signal (H:Voice exist / L:Voice is absence)
(not used (Fixed to Ground))
201 Fixed_Low Not used (Open)
202 ASDATA1 O Audio serial data 1: SL/SR
203 ASDATA2 O Audio serial data 2: C/SW
204 Fixed_Low Not used (Open)
205 Fixed_Low Not used (Open)
206 Fixed_Low Not used (Open)
207 Fixed_Low Not used (Open)
208 DVDD3 Power supply (SW+3.3V)
209 ALRCK O Audio left/right channel clock output
210 ABCK O Audio bit clock output
211 ACLK O Master clock output for Audio DAC
212 ADIN I Ex. Analog Audio data input
213 DVDD18 Power supply (+1.8V from IC1110)
214 ASDATA4 O Audio serial data 0: FL/FR
215 MC_DATA I Mic signal Input (not used (Fixed to Ground))
216 SPDIF O SPDIF output
217 APLLVDD3 Power supply (+3.3V from IC1105)
218 APLLCAP I APLL External Capacitance connection
219 APLLVSS Ground terminal
220 ADACVSS2 Ground terminal
221 ADACVSS1 Ground terminal
222 KMOD O Karaoke mode status output (H:Karaoke / L:Normal) (not used (Open))
223 PWON O Power down control signal to HDMI controller
224 Rch O Audio DAC Right channel output (not used (Open))
225 AVCM Audio DAC Reference Voltage
226 Lch O Audio DAC Left channel output (not used (Open))
227 DSEL O Interlace/Progressive select output signal (H:480i / L:480p) (not used (Open))
228 xRST O Reset output signal for ADAC (Low Active) (not used (Open))
229 ADACVDD1 Power supply (+3.3V from IC1105)
230 ADACVDD2 Power supply (+3.3V from IC1105)
231 RFGND18 Ground terminal
232 RFVDD18 Power supply (+1.8V from IC1110)
233 XTALO O 27MHz crystal output (not used (Open))
234 XTALI I 27MHz crystal input
235 JITFO O The output terminal of RF jitter meter
236 JITFN I The input terminal of RF jitter meter
237 PLLVSS Ground terminal
238 IDACEXLP I RF Data PLL DAC LPF
239 PLLVDD3 Power supply (RF+3.3V)
240 LPFON O The negative output of loop filter amplifier
241 LPFIP I The positive input terminal of loop filter amplifier
242 LPFIN I The negative input terminal of loop filter amplifier
243 LPFOP O The positive output of loop filter amplifier
244 ADCVDD3 Power supply (RF+3.3V)
245 ADCVSS Ground terminal
