76
HCD-DZ230/DZ231/HDZ235
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CN308 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D271 6-501-193-01 DIODE 1SS355WTE-17
D272 6-501-193-01 DIODE 1SS355WTE-17
D309 8-719-058-24 DIODE RB501V-40TE-17
< IC >
IC202 6-703-622-01 IC MM1508XNRE
IC230 6-707-489-01 IC BH7868FS-E2
IC303 8-759-385-76 IC MC14052 BDR2
IC306 8-759-100-96 IC uPC4558G2
IC307 6-703-550-01 IC TA7809LS
< JACK >
J230 1-816-044-11 CONNECTOR, SQUARE TYPE 21P
(EURO AV / T OUTPUT(TO TV))
< COIL >
L221 1-469-525-91 INDUCTOR 10uH
L231 1-469-525-91 INDUCTOR 10uH
L304 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q271 1-801-806-11 TR DTC144EKA
Q272 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q273 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q274 1-801-806-11 TR DTC144EKA
Q275 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q276 1-801-806-11 TR DTC144EKA
Q279 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q305 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q307 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R210 1-218-285-11 METAL CHIP 75 5% 1/10W
R211 1-218-285-11 METAL CHIP 75 5% 1/10W
R212 1-218-285-11 METAL CHIP 75 5% 1/10W
R221 1-216-864-11 SHORT CHIP 0
R222 1-216-864-11 SHORT CHIP 0
R225 1-218-285-11 METAL CHIP 75 5% 1/10W
R244 1-218-285-11 METAL CHIP 75 5% 1/10W
R245 1-218-285-11 METAL CHIP 75 5% 1/10W
R246 1-218-285-11 METAL CHIP 75 5% 1/10W
R250 1-216-864-11 SHORT CHIP 0
R271 1-216-821-11 METAL CHIP 1K 5% 1/10W
R272 1-216-841-11 METAL CHIP 47K 5% 1/10W
R273 1-216-849-11 METAL CHIP 220K 5% 1/10W
R274 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R275 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R276 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R277 1-216-821-11 METAL CHIP 1K 5% 1/10W
R278 1-216-837-11 METAL CHIP 22K 5% 1/10W
R279 1-216-815-11 METAL CHIP 330 5% 1/10W
R280 1-216-815-11 METAL CHIP 330 5% 1/10W
R281 1-216-815-11 METAL CHIP 330 5% 1/10W
R282 1-216-815-11 METAL CHIP 330 5% 1/10W
R285 1-216-833-11 METAL CHIP 10K 5% 1/10W
R303 1-216-864-11 SHORT CHIP 0
R308 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R309 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R310 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R311 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R316 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R320 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R324 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R332 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R335 1-216-841-11 METAL CHIP 47K 5% 1/10W
R336 1-216-841-11 METAL CHIP 47K 5% 1/10W
R337 1-216-841-11 METAL CHIP 47K 5% 1/10W
R338 1-216-841-11 METAL CHIP 47K 5% 1/10W
R341 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R344 1-216-841-11 METAL CHIP 47K 5% 1/10W
R345 1-216-841-11 METAL CHIP 47K 5% 1/10W
R346 1-216-841-11 METAL CHIP 47K 5% 1/10W
R347 1-216-841-11 METAL CHIP 47K 5% 1/10W
R351 1-216-864-11 SHORT CHIP 0
R363 1-216-841-11 METAL CHIP 47K 5% 1/10W
R364 1-216-841-11 METAL CHIP 47K 5% 1/10W
R365 1-216-841-11 METAL CHIP 47K 5% 1/10W
R366 1-216-841-11 METAL CHIP 47K 5% 1/10W
R380 1-216-864-11 SHORT CHIP 0
R384 1-216-864-11 SHORT CHIP 0
R392 1-216-833-11 METAL CHIP 10K 5% 1/10W
R394 1-216-821-11 METAL CHIP 1K 5% 1/10W
R396 1-216-833-11 METAL CHIP 10K 5% 1/10W
R398 1-216-841-11 METAL CHIP 47K 5% 1/10W
R399 1-216-841-11 METAL CHIP 47K 5% 1/10W
R400 1-216-821-11 METAL CHIP 1K 5% 1/10W
R402 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R403 1-216-845-11 METAL CHIP 100K 5% 1/10W
R404 1-216-845-11 METAL CHIP 100K 5% 1/10W
R405 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R406 1-216-845-11 METAL CHIP 100K 5% 1/10W
R407 1-216-845-11 METAL CHIP 100K 5% 1/10W
R408 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R409 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R410 1-216-841-11 METAL CHIP 47K 5% 1/10W
R411 1-216-841-11 METAL CHIP 47K 5% 1/10W
R412 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R413 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R414 1-216-817-11 METAL CHIP 470 5% 1/10W
R415 1-216-817-11 METAL CHIP 470 5% 1/10W
R416 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R417 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R420 1-216-817-11 METAL CHIP 470 5% 1/10W
R421 1-216-817-11 METAL CHIP 470 5% 1/10W
*************************************************************
A-1236-513-A IO-S-OUT BOARD, COMPLETE (HDZ235)
************************
< CAPACITOR >
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
