85
HCD-DZ230/DZ231/HDZ235
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R1109 1-216-864-11 SHORT CHIP 0
R1110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1111 1-216-809-11 METAL CHIP 100 5% 1/10W
R1112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R1113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R1114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R1116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1118 1-216-801-11 METAL CHIP 22 5% 1/10W
R1120 1-216-801-11 METAL CHIP 22 5% 1/10W
R1121 1-216-801-11 METAL CHIP 22 5% 1/10W
R1123 1-216-864-11 SHORT CHIP 0
R1124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1125 1-216-805-11 METAL CHIP 47 5% 1/10W
R1132 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1133 1-216-864-11 SHORT CHIP 0
R1134 1-216-864-11 SHORT CHIP 0 (DZ230/DZ231)
R1135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1138 1-216-809-11 METAL CHIP 100 5% 1/10W
R1139 1-216-864-11 SHORT CHIP 0
R1140 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1141 1-216-855-11 METAL CHIP 680K 5% 1/10W
R1142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1145 1-216-864-11 SHORT CHIP 0
R1147 1-216-864-11 SHORT CHIP 0
R1148 1-216-864-11 SHORT CHIP 0
R1151 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1152 1-216-864-11 SHORT CHIP 0
R1153 1-216-864-11 SHORT CHIP 0
R1154 1-216-864-11 SHORT CHIP 0
R1155 1-216-864-11 SHORT CHIP 0
R1156 1-216-809-11 METAL CHIP 100 5% 1/10W
R1159 1-216-805-11 METAL CHIP 47 5% 1/10W
R1160 1-216-805-11 METAL CHIP 47 5% 1/10W
R1161 1-216-801-11 METAL CHIP 22 5% 1/10W
R1169 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1170 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1171 1-216-809-11 METAL CHIP 100 5% 1/10W
R1175 1-216-864-11 SHORT CHIP 0
R1183 1-216-805-11 METAL CHIP 47 5% 1/10W
R1184 1-216-805-11 METAL CHIP 47 5% 1/10W
R1185 1-216-805-11 METAL CHIP 47 5% 1/10W
R1191 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1193 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1204 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R1205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1207 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R1208 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1209 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1210 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1212 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1213 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1214 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1215 1-216-834-11 METAL CHIP 12K 5% 1/10W
R1216 1-216-834-11 METAL CHIP 12K 5% 1/10W
R1219 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1220 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1221 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R1222 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1223 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1225 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1226 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R1227 1-216-864-11 SHORT CHIP 0
R1228 1-216-864-11 SHORT CHIP 0
R1230 1-218-893-11 METAL CHIP 82K 0.5% 1/10W
R1231 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R1232 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R1233 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R1234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1236 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1237 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1238 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1239 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1243 1-216-809-11 METAL CHIP 100 5% 1/10W
R1246 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1247 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1601 1-216-295-91 SHORT CHIP 0
R1602 1-216-295-91 SHORT CHIP 0
R1603 1-216-295-91 SHORT CHIP 0
R1604 1-216-295-91 SHORT CHIP 0
R1605 1-216-296-11 SHORT CHIP 0
R1606 1-216-295-91 SHORT CHIP 0
R1701 1-216-809-11 METAL CHIP 100 5% 1/10W
R1702 1-216-864-11 SHORT CHIP 0
R1703 1-216-864-11 SHORT CHIP 0
R1704 1-216-809-11 METAL CHIP 100 5% 1/10W
R1705 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1706 1-216-864-11 SHORT CHIP 0
R1707 1-216-864-11 SHORT CHIP 0
R1712 1-216-809-11 METAL CHIP 100 5% 1/10W
R1713 1-218-841-11 METAL CHIP 560 0.5% 1/10W
R1714 1-216-864-11 SHORT CHIP 0
R1721 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1722 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1723 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1726 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1727 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1728 1-216-864-11 SHORT CHIP 0
R1730 1-218-840-11 METAL CHIP 510 0.5% 1/10W
R1731 1-216-864-11 SHORT CHIP 0
R1734 1-216-864-11 SHORT CHIP 0
R1736 1-216-864-11 SHORT CHIP 0
R1738 1-216-864-11 SHORT CHIP 0
R1740 1-216-864-11 SHORT CHIP 0
R1742 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1744 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1746 1-216-864-11 SHORT CHIP 0
R1747 1-216-864-11 SHORT CHIP 0
R1748 1-216-864-11 SHORT CHIP 0
R1749 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R1750 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
MAIN
