89
HCD-DZ230/DZ231/HDZ235
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C948 1-126-925-91 ELECT 470uF 20% 10V
C949 1-104-658-91 ELECT 100uF 20% 10V
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C952 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C953 1-117-214-11 CERAMIC 0.001uF 10% 2KV
C954 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C955 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C958 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C960 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
0 C963 1-117-697-51 CERAMIC 470PF 10% 250V
(DZ230/DZ231)
0 C963 1-117-700-51 CERAMIC 0.0022uF 20% 250V
(HDZ235)
0 C964 1-117-697-51 CERAMIC 470PF 10% 250V
(DZ230/DZ231)
0 C964 1-117-700-51 CERAMIC 0.0022uF 20% 250V
(HDZ235)
C967 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C968 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C969 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C970 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C971 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
0 C980 1-117-828-11 FILM 3300PF 3% 1.5KV
(HDZ235)
C981 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(DZ230/DZ231)
< CONNECTOR >
0 CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN906 1-564-714-11 PIN, CONNECTOR (SMALL TYPE) 12P
CN907 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
(DZ230/DZ231)
< DIODE >
0 D901 8-719-082-57 DIODE D5SBA60F01
0 D905 8-719-063-74 DIODE D1NL20U-TR2
0 D906 6-501-193-01 DIODE 1SS355WTE-17
0 D907 6-501-193-01 DIODE 1SS355WTE-17
0 D908 6-501-193-01 DIODE 1SS355WTE-17
0 D909 6-501-193-01 DIODE 1SS355WTE-17
0 D910 6-501-193-01 DIODE 1SS355WTE-17
0 D913 6-500-241-01 DIODE SARS03
0 D914 6-501-193-01 DIODE 1SS355WTE-17
0 D915 6-501-174-01 DIODE UDZW-TE17-10B
0 D921 6-501-424-01 DIODE STO2D-140
0 D922 8-719-063-74 DIODE D1NL20U-TR2
0 D923 6-501-174-01 DIODE UDZW-TE17-10B
0 D924 6-501-183-01 DIODE UDZW-TE17-24B
0 D925 6-501-167-01 DIODE UDZW-TE17-5.1B
0 D926 6-501-174-01 DIODE UDZW-TE17-10B
D931 6-501-849-01 DIODE FMX-22SL
D932 6-501-167-01 DIODE UDZW-TE17-5.1B
D941 6-500-288-11 DIODE EK19LF-F7
D942 8-719-080-53 DIODE RK36LF-B3
D943 8-719-080-53 DIODE RK36LF-B3
D944 6-500-288-11 DIODE EK19LF-F7
D945 6-501-181-01 DIODE UDZW-TE17-20B
< TERMINAL BOARD >
EB901 1-537-770-21 TERMINAL BOARD, GROUND
EB902 1-537-770-21 TERMINAL BOARD, GROUND
EB903 1-537-770-21 TERMINAL BOARD, GROUND
EB904 1-537-770-21 TERMINAL BOARD, GROUND
EB906 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< FUSIBLE RESISTOR >
0FR901 1-242-949-11 FUSIBLE 0.1 10% 1W
(DZ230/DZ231)
< IC >
0IC901 6-707-741-01 IC STR-F6138-LF1352 (HDZ235)
0IC901 6-707-742-01 IC STR-F6168-LF1352 (DZ230/DZ231)
0IC921 6-707-740-01 IC STR-V153
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-705-308-01 IC SI-3010KM-TL
IC942 6-705-308-01 IC SI-3010KM-TL
IC943 6-705-308-01 IC SI-3010KM-TL
IC951 6-707-743-01 IC TA76L431S (TPE6, Q)
< COIL >
L931 1-457-438-11 COIL, CHOKE 5.6uH
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L943 1-414-398-11 INDUCTOR 10uH
L944 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L951 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0LF901 1-457-054-21 COIL, LINE FILTER
0LF902 1-457-054-21 COIL, LINE FILTER
< PHOTO COUPLER >
0PC901 6-600-438-01 IC TLP421F (D4-GR)
0PC902 6-600-438-01 IC TLP421F (D4-GR)
0PC903 6-600-438-01 IC TLP421F (D4-GR)
< TRANSISTOR >
0Q901 8-729-141-88 TRANSISTOR 2SB1116A-TP-LK
0Q921 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q943 1-801-806-11 TR DTC144EKA
Q945 6-550-718-01 TRANSISTOR RSR025N03TL
Q947 1-801-806-11 TR DTC144EKA
< RESISTOR >
0R901 1-219-759-11 METAL 1M 5% 1/2W
0R903 1-215-926-00 METAL OXIDE 33K 5% 3W F
(HDZ235)
0R903 1-215-929-11 METAL OXIDE 100K 5% 3W F
(DZ230/DZ231)
