HCD-DZ230/DZ231/HDZ235
Ref. No. Part No. Description Remark
< TERMINAL >
TB301 1-780-454-11 TERMINAL BOARD (SPEAKER) 4P
(SPEAKER FRONT R/FRONT L/SUR R/SUR L)
*************************************************************
MISCELLANEOUS
**************
5 1-828-307-51 WIRE (FLAT TYPE)(9 CORE) (DZ230/DZ231)
7 1-828-952-51 WIRE (FLAT TYPE)(9 CORE) (HDZ235)
7 1-828-962-51 WIRE (FLAT TYPE)(11 CORE) (DZ230/DZ231)
8 1-693-724-11 TUNER (FM/AM) (DZ230/DZ231)
8 1-693-731-11 TUNER (FM/AM) (HDZ235)
59 1-828-325-51 WIRE (FLAT TYPE)(13 CORE)
61 1-828-374-51 WIRE (FLAT TYPE)(21 CORE)
102 1-828-292-51 WIRE (FLAT TYPE)(5 CORE)
103 1-828-339-51 WIRE (FLAT TYPE)(15 CORE) (HDZ235)
103 1-828-369-51 WIRE (FLAT TYPE)(21 CORE) (DZ230/DZ231)
104 1-828-317-51 WIRE (FLAT TYPE)(11 CORE) (HDZ235)
104 1-828-327-51 WIRE (FLAT TYPE)(13 CORE) (DZ230/DZ231)
109 1-787-331-11 FAN, D.C.
0 110 1-751-520-31 CORD, POWER (UK)
0 110 1-830-188-11 CORD, POWER (AEP)
0 110 1-830-190-11 CORD, POWER (HDZ235)
0 507 8-820-321-05 OPTICAL PICK UP ASSY KHM-313CAA/C2RP
508 1-828-773-51 WIRE (FLAT TYPE)(24 CORE)
0 F901 1-533-311-12 FUSE,GLASS CYLINDRICAL (DIA.5) (8A/125V)
(HDZ235)
0 F901 1-576-233-51 FUSE (H.B.C.) (T6.3AH/250V)(DZ230/DZ231)
