81
HCD-DZ520K/DZ620K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C305 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C306 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C307 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C311 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C314 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C315 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C316 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C317 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C318 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C319 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C320 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C321 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C322 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C323 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C324 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
* CN301 1-564-519-11 PLUG, CONNECTOR 4P
CN302 1-818-651-11 PIN, CONNECTOR 2P
* CN303 1-564-521-11 PLUG, CONNECTOR 6P
< EARTH TERMINAL >
EP301 1-537-770-21 TERMINAL BOARD, GROUND
EP302 1-537-770-21 TERMINAL BOARD, GROUND
< TERMINAL >
TB301 1-780-344-11 TERMINAL BOARD (SPEAKER) 4P
(FRONT R)(FRONT L)(CENTER)(WOOFER)
TB302 1-780-343-11 TERMINAL BOARD (SPEAKER) 2P
(SUR R)(SUR L)
*************************************************************
SW BOARD
*********
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (?/1)
*************************************************************
MISCELLANEOUS
**************
3 1-693-701-11 TUNER (FM/AM) (TM10SKR) (RU)
3 1-693-702-11 TUNER (FM/AM) (TM10SE) (E3, SP)
8 1-828-953-11 WIRE (FLAT TYPE)(9 CORE)
65 1-828-384-11 WIRE (FLAT TYPE)(23 CORE)
66 1-828-325-11 WIRE (FLAT TYPE)(13 CORE)
104 1-787-331-11 FAN, D.C.
0 106 1-777-071-22 CORD, POWER (E3)
0 106 1-830-188-11 CORD, POWER (RU, SP)
110 1-828-292-11 WIRE (FLAT TYPE)(5 CORE)
111 1-828-332-11 WIRE (FLAT TYPE)(13 CORE)
112 1-828-300-11 WIRE (FLAT TYPE)(7 CORE)
113 1-828-330-11 WIRE (FLAT TYPE)(13 CORE)
0507 8-820-290-02 OPTICAL PICK-UP KHM-310CAA/C2RP
508 1-828-773-51 WIRE (FLAT TYPE)(24 CORE)
0F901 1-532-325-00 FUSE, TIME-LAG (T6.3AL/250V)
