Sony HCD-EC619iP Service Manual

HCD-EC719iP/EC919iP
7
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
2-2. SIDE COVER,
TOP COVER BLOCK
(Page 8)
SET
2-3. POWER CORD (AC1),
REAR PANEL BLOCK
(Page 9)
2-4. CD DOOR
(Page 10)
2-6. MAIN BOARD BLOCK
(Page 11)
2-8. POWER BOARD
(Page 12)
2-7. MAIN BOARD
(Page 11)
2-10. USB BOARD
(Page 14)
2-11. LOADER WITH FFC (TDL-5) (CDM1)
(Page 14)
2-9. FRONT BOARD
(Page 13)
2-5. FRONT PANEL BLOCK
(Page 10)
