• Waveforms
– MB Board –
316 mVp-p
8.0 kHz
2 IC100 qa (O-XOUT)
100 mV/DIV, 50 ns/DIV
88 mVp-p
24.0 MHz
4 IC300 es (XTALOUT)
20 mV/DIV, 10 ns/DIV
6 IC701 4 (XTALO)
50 mV/DIV, 25 ns/DIV
12.28 MHz
152 mVp-p
1 IC100 9 (O-XC-OUT)
50 mV/DIV, 10 P s/DIV
32.76 kHz
180 mVp-p
3 IC100 <z// (O-FL-CLK)
200 mV/DIV, 25 ns/DIV
1 Ps
352 mVp-p
5 IC501 8 (XTALO)
20 mV/DIV, 10 ns/DIV
94 mVp-p
27.0 MHz
