Sony HCD-GPX33 - DISASSEMBLY PROCEDURE OVERVIEW; DISASSEMBLY FLOWCHART

HCD-GPX33/GPX55/GPX77/GPX88
8
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
2-2. SIDE-L PANEL, SIDE-R PANEL,
TOP PANEL
(Page 9)
2-5. CD MECHANISM SECTION
(CDM90-DVBU202//M)
(Page 10)
2-7. CHASSIS SECTION
(Page 11)
2-8.
SERVICE OPTICAL DEVICE,
WIRE (FLAT TYPE)
(Page 12)
2-6. MB BOARD
(Page 11)
2-4. FRONT PANEL SECTION
(Page 10)
SET
2-3. LOADING PANEL
(Page 9)
